FAD-220F

Experience advanced application delivery with Fortinet FAD-220F, part of the Collsam Distribution of Cybersecurity family. Protect your network and data with Fortinet Security Fabric Front View.

FAD-220F

$11,700.00

In stock

$11,700.00

Fortinet FortiADC 220F application accelerator FAD-220F

  • Application Security
  • 4 Port
  • 1000Base-T
  • 1000Base-X
  • Gigabit Ethernet
  • AES
  • SHA-256
  • 4 x RJ-45
  • 4 Total Expansion Slots
  • 1 Year FortiCare Premium and FortiADC ADV Bundle
  • 1U – Rack-mountable

Compare

Description

Introducing the Fortinet FAD-220F, a cutting-edge Application Delivery Controller designed to provide advanced protection for your network and applications. This device has 4 ports for RJ45 and 4 ports for SFP. It is capable of meeting the needs of your growing business. The FortiADC features one GE RJ45 management port and one console port, ensuring maximum effectiveness and streamlined administration.

The FortiADC FAD-220F is a security solution that integrates with the Fortinet Security Fabric. This system makes sure your whole network and programs are safe from all sides. With FortiADC, you can make a strong security system that can protect your apps and data.

The FAD-220F is part of the Collsam Distribution of Cybersecurity collection. The FortiADC has met high standards of security with high standards of security. A proven and trusted solution protects your critical business applications.

The FAD-220F also offers a single power supply, making it simple and cost-effective to deploy. The FortiADC is straightforward to utilize without requiring extensive instruction. This allows your IT team to focus on other critical tasks, while the FortiADC seamlessly handles application delivery and protection.

It is important to have a robust and comprehensive solution to protect your network and applications. With the Fortinet FAD-220F, you can rest assured that your critical business applications are in safe hands. So why wait? Upgrade to the FortiADC today and experience a new level of application delivery and security.

Additional information

Weight20 lbs
Dimensions22 × 22 × 8 in
IP Telephony
VoIP ProtocolsSIP
Miscellaneous
Compliant StandardsCSA, UL, ULC, FCC Part 15 A, VCCI Class A, RCM
Networking
Form FactorRack-mountable
Connectivity TechnologyWired
Data Link ProtocolGigabit Ethernet
Network / Transport ProtocolTCP/IP, UDP/IP, FTP, DNS, RTMP, RTSP, HTTP, HTTPs, IPv4, IPv6
Routing ProtocolOSPF, BGP
Remote Management ProtocolSNMP, HTTP, HTTPS, SSH, CLI, JSON, LDAP, RADIUS
PerformanceLayer 4 throughput: 5 Gbps ¦ Layer 7 throughput: 4 Gbps ¦ Layer 4 throughput: 160000 connections per second ¦ Layer 4 HTTP throughput: 500000 requests per second ¦ Layer 7 throughput: 40000 connections per second ¦ SSL (1:1) 2K keys: 1200 connections per second ¦ SSL bulk encryption throughput: 1.2 Gbps ¦ Compression throughput: 2 Gbps
CapacityConcurrent Layer 4 connections: 6000000 ¦ Virtual domains: 10
FeaturesNAT support, VPN support, SNAT support, VLAN support, Syslog support, DDoS attack prevention, Global Server Load Balancing (GSLB), antivirus protection, Virtual Extensible LAN (VXLAN), Network Virtualization using Generic Routing Encapsulation (NVGRE), Web Application Firewall (WAF), Hardware Security Module (HSM) support, Disaster Recovery technology. Port trunking, Link Load Balancing (LLB), RESTful APIs, DNSSEC support.
Encryption AlgorithmSSL, 256-bit AES, 256-bit SHA, TLS 1.3
Authentication MethodKerberos, RADIUS, LDAP, NTLM, SAML 2.0
Environmental Parameters
Min Operating Temperature32 °F
Max Operating Temperature104 °F (40 °C)
Humidity Range Operating5 – 95% (non-condensing)
General
Device TypeApplication accelerator
Height (Rack Units)1U
Width17.2 in
Depth16.4 in
Height1.7 in
Weight20 lbs
Processor / Memory / Storage
RAM8 GB
Hard DriveSSD 120 GB x 1
Expansion / Connectivity
Interfaces4 x 1000Base-T – RJ-45 ¦ 4 x 1000Base-X – SFP
Power
Power DeviceInternal power supply
Installed Qty1
Voltage RequiredAC 100-240 V (50/60 Hz)
Power Consumption Operational80 Watt
