CIR-B2202

CIR-B2202 HD-CVI 1080p(2MP) IR Bullet Camera

CIR-B2202

Original price was: $39.99.Current price is: $28.95.

In stock

Original price was: $39.99.Current price is: $28.95.

Truon CIR-B2202 HD-CVI IR Bullet 1080P 3.6MM Fixed Lens

  • 1/2.8” megapixel sensor
  • HD-CVI 1080P High Definition
  • 3.6 mm Mega Pixel Lens
  • Weatherproof Housing IP 66
  • High-quality IR Cut Filter
  • 24 pcs IR LEDs
  • 15 m IR distance

Description

The Eyemax CIR-B2202 is a top-of-the-line surveillance camera. Its purpose is to transmit high-definition video over existing coaxial cables. This 2-megapixel (1080p) HD-CVI IR bullet camera is the perfect choice for those looking for excellent image quality and reliable performance. Furthermore, with its 3.6 mm fixed lens and 82° view, it can capture a wide area. It also provides crisp, clear images in both day and night settings.

Featuring infrared night vision, the Eyemax CIR-B2202 can provide surveillance even in the darkest of environments. The camera’s 24 IR LEDs enable this by preventing “infrared halo” effects and guaranteeing the best possible quality of the footage. Furthermore, with a 1080p Full-HD resolution at up to 25 frames per second, you can expect nothing less than top-notch surveillance footage from this camera.

The camera’s IP67 rating makes it suitable for outdoor use. It can withstand harsh weather conditions such as rain, snow, and extreme temperatures. This is due to its weather-resistant housing, which is designed to protect the camera from the elements and ensure its longevity.

In addition, the camera is also available in both white (CIR-B2202-W) and gray (CIR-B2202-B) versions. This allows you to choose the one that best suits your needs and preferences.

The Eyemax CIR-B2202 is designed for convenience and ease of use. It uses standard coaxial cable infrastructure, which means that you can install it without the need for complicated wiring. This also implies that there are no extra costs involved in integrating it with your current surveillance system.

Furthermore, the camera features an HD/SD switchable output, which enables compatibility with various recording systems. As a result, you have the flexibility to use it with different devices.

Equipped with a 1/2.8” CMOS sensor and Wide Dynamic Range (WDR) technology, the Eyemax CIR-B2202 allows for clear footage even in challenging lighting conditions. This makes it an ideal choice for areas with varying levels of light. You will also ensure that you don’t miss any important details in your surveillance.

It is also suitable for both outdoor and indoor mounting, thanks to its rugged housing that can withstand both indoor and outdoor environments. Overall, the Eyemax CIR-B2202 is a reliable and high-performing camera. It offers exceptional surveillance capabilities, making it an excellent choice for your security needs.

Datasheet

Download

CIR-B2202 HD-CVI 1080p(2MP) IR Bullet Camera Datasheet

Image Sensor:1/2.8” Mega Pixel Sensor
Effective Pixels:2.0 Mega Pixels
Built-in Lens:3.6mm Mega Pixel Lens
Signal System:PAL/NTSC
Horizontal ResolutionPAL: 1920 × 1080P 25F/S NTSC: 1920 × 1080P 30F/S
Sync. System:Internal Sync.
Sensor Area:5.42 mm × 3.41mm
Video Output:1.0Vp~p75Ω
S/N Ratio:More than 50 dB (AGC OFF)
White Balance:Auto Tracking White Balance
Shutter Speed:1/25 ~ 1/50,000Sec.
Illumination for Infrared Switching3 Lux
Infrared Wavelength:850nm
Mimimum Illumination:0 Lux (Infrared Lamps Turn on)
IR Leds:24pcs
IR Radiation Distance:50ft(15m)
Weather-proof:IP66
Working Temperature:14°F (-10°C) ~ 122°F (50°C)
Storage Temperature:-4°F (-20°C) ~ 140°F (60°C)
Power Requirement:DC12V, max power consumption less than 5W (when the infrared lamps turn on)
Weight:1.1 lb (0.5 kg)

Additional information

Weight1.5 lbs
Dimensions10 × 3 × 5 in
