UVI-2544V

Eyemax UVI-2544V STORM® dome camera. Full HD 1080p, 720p resolution, 1/2.9” Sony CMOS sensor, and COB IR for night vision. Vandal-proof, IP68 rated, and balun compatible. Dual power, DNR, ICR, and Shield anti-IR reflection technology. Available in White or ivory. Made in Korea.

UVI-2544V

Out of stock
0 out of 5

Eyemax UVI-2544V EX-SDI 1080p 2-megapixel IP68 Dome Camera with Dual Power and 4 COB IR Anti-IR Reflection

  • 1080p 2-megapixelFULL HD Flawless Video
  • 1/2.9” Sony CMOS
  • 2.8~12 mm Auto-Iris Varifocal Lens
  • 0 Lux at IR On 4 pcs COB IR
  • Upgraded Waterproof Housing IP68 ingress protection
  • Smart IR / DNR (Digital Noise Reduction) / True Day & Night (ICR)
  • RS-485 Option
  • Easy Installation
  • DC 12V or AC 24V
Eyemax security cameras and video surveillance products at Collsam SecurityNDAA-compliant security products at Collsam Security
This product has been discontinued

Description

Eyemax UVI-2544V STORM® EX-SDI and HD-SDI-enabled Full HD 1080p 2-megapixel dome camera is the most advanced security camera available. With its cutting-edge technology and many useful features, this dome camera is a great addition to any security system.

This camera stands out because it can record and play back high-quality videos. It works with both EX-SDI and HD-SDI formats. This feature also allows for seamless integration with other EX-SDI and HD-SDI-enabled devices, providing a comprehensive security solution. The camera also supports 720p resolution, giving users the option to choose the recording resolution depending on their needs.

A 1/2.9” Sony CMOS sensor built into the camera ensures crisp, clear video even in low light. Four COB infrared cameras let it record video in total darkness (0 lux on infrared) for better surveillance at night. This makes it perfect for use outside, protecting your property at all times.

This camera’s 2.8–12 mm auto-iris Varifocal lens, which has adjustable focus and zoom, is another noteworthy feature. The lenses can be adjusted to capture the subject from various perspectives and distances. The camera is weather-resistant and can be used outdoors for an extended period of time, thanks to its IP68 rating.

The Eyemax UVI-2544V STORM® camera is also compatible with balun technology, allowing for easy and cost-effective installation. Both 12V DC and 24V AC power sources can power it, giving users options and making things easier.

The camera has two cool features that improve video recordings overall: Digital Noise Reduction (DNR) and True Day & Night (ICR). Additionally, the camera features Shield anti-IR reflection technology, preventing washed-out videos caused by IR reflections.

Korea designs and makes the reliable and high-quality Eyemax UVI-2544V STORM® EX-SDI and HD-SDI-enabled Full HD 1080p 2-megapixel dome camera. It provides a comprehensive array of features and functionalities.

This camera is a good buy that gives you peace of mind and reliable security monitoring. You can use it for business or at home. Available in both white and ivory colors, this camera also adds a touch of aesthetic appeal to any property.

Datasheet

Download

Eyemax UVI-2544V STORM® dome camera. Full HD 1080p, 720p resolution, 1/2.9” Sony CMOS sensor, and COB IR for night vision. Vandal-proof, IP68 rated, and balun compatible. Dual power, DNR, ICR, and Shield anti-IR reflection technology. Available in White or ivory. Made in Korea. Datasheet!

ResolutionHD-SDI (1080P, 720P) / 1000 TV LINE OVER
Sensor1/ 3 INCH SONY CMOS
Total Pixels2010(H) × 1108(V) = 2,227,080
Effective Pixels1944(H) × 1092(V) = 2,122,648
Scanning SystemPROGRESSIVE
S/ N (Y signal)More than 52 dB (AGC Off)
Video OutputSMPTE292M (HD-SDI) / CVBS: 1.0Vp-p (75 ohm)
Min.Illumination0 Lux at IR On
White BalanceAUTO / AUTO EXT / PUSHING / MANUAL
Electronic shutter speedAUTO / Manual (1/ 30sec ~ 1/ 60,000sec)
BrightnessADJUSTABLE (0 ~ 20 STEP)
SENS_UPOFF / × 2 / × 3 / × 4
DNROFF / LOW / MIDDLE / HI
WDR/ BLCOFF / WDR / BLC
HLMOFF / SET
ACEOFF / ON
Day & NightAUTO (Day <–> Night TIME Change) , COLOR , Black and White, EXTERN, MDIR
Smart IROFF / ON
PrivacyOFF / ON (31 Zone)
Motion DetectionOFF / ON
D.ZOOM0 ~ × 127
FLIPOFF / ON
FREEZEOFF / ON
Image ConversionOFF / ON
LanguageENGLISH
SharpnessADJUSTABLE (0 ~ 10 STEP)
COMM.RS-485(PELCO-D)
Operating Temperature/ Humidity14 °F (-10 °C) ~ 122 °F (50 °C) / 30% ~ 80% RH
Storage  Temperature/Humidity-4 °F (-20 °C) ~ 140 °F (60 °C) / 20% ~ 90% RH
PowerDC 12V or AC 24V
Signal328.08 ft (100 m) ~ 492.13 ft (150 m) Max transmission range depends on the cable manufacturer and the installation environment.

Additional information

Weight4 lbs
Dimensions9 × 9 × 9 in
