EYEMAX UVI-M2562V-W Anti-IR Reflection 1080P EX-SDI and HD-SDI Storm® IR IP68 Dome Camera with Motorized Varifocal Lens

  • MOTORIZED 2.8~12mm Auto-Iris VariFocal Lens
  • 1080p FULL HD Flawless Video
  • 1/2.9” Sony CMOS
  • 0 Lux at IR On (COB IR : 6pcs)
  • Upgraded Waterproof Housing (IP68 Rating)
  • Smart IR / DNR (Digital Noise Reduction) / True Day & Night (ICR)
  • RS-485 Option
  • Easy Installation
  • DC 12V
Eyemax LogoCollsam Security NDAA
Eyemax Logo SKU: UVI-M2562V UPC: 658294504065 Categories: , Tags: , , , , , , , , , , , ,

Description

The Eyemax UVI-M2562V is a state-of-the-art surveillance camera. It is perfect for professional-grade security and monitoring purposes. The technology and features in this IR dome camera are the best on the market. Thus, making it a reliable and versatile choice for any surveillance needs. With its advanced EX-SDI/HD-SDI technology, this camera can provide high-definition video over coaxial cabling. This ensures crisp and clear images at all times.

One of the standout features of the Eyemax UVI-M2562V is its 1080p Full-HD resolution. It boasts a stunning 2 Megapixels for superior image quality. Because of its high-quality imaging capabilities, the camera’s 1/2.9” Sony CMOS sensor makes this possible.

Additionally, the camera’s motorized 2.8~12mm auto-iris Varifocal lens allows for remote zoom and focus adjustments. This allows users the flexibility to adjust the camera’s field of view without having to physically reposition it.

The UVI-M2562V also offers hybrid EX-SDI and HD-SDI technology. Depending on what you require, you can easily switch between them. This feature allows for long-distance transmission of video signals over standard coaxial cable. Thus, making it a cost-effective and reliable option for installation.

Furthermore, this camera comes with an IP68 waterproof rating. This makes it submersible and suitable for outdoor use. Its “STORM” housing is also vandal-proof, providing added protection against tampering and damage.

With 6 COB (chip on board) IR LEDs, the UVI-M2562V can capture clear images even in zero-lux conditions. This makes it an ideal choice for nighttime surveillance. No information will be overlooked, regardless of the availability of light.

The camera also features “The Shield” technology. This prevents washed-out videos caused by IR light reflecting off obstacles such as water or oil on the cover. This ensures that your footage remains clear and highly detailed at all times.

In addition, the Eyemax UVI-M2562V includes essential features. These include True Day & Night (ICR), Digital Noise Reduction (DNR), and Smart IR. With these functions, the camera can produce clear and high-quality images in various lighting conditions. This provides round-the-clock surveillance coverage.

It is also backward compatible with HD-SDI systems. This makes it a versatile choice for those who are looking to upgrade their existing security setup. Furthermore, it is compatible with specialized video baluns for UTP cable installation. This allows users the flexibility to choose their preferred method of installation.

Datasheet

Download

Protect your property with the Eyemax UVI-M2562V, a high-definition 1080p EX-SDI/HD-SDI IR dome camera. Waterproof, vandal-proof, and equipped with advanced features for clear and reliable surveillance. Ideal for professional-grade security. In ivory or white Color Datashewet.

Resolution1080p, 720p, 720p CROP
Sensor1/2.9 inch SONY CMOS (IMX-222 / IM × 322)
Total Pixels2000(H) × 1241(V) = 2,482,000
Effective Pixels1944(H) × 1092(V) = 2,122,648
Scanning SystemProgressive
S/N (Y Signal)More than 52 dB (AGC Off)
Video OutputSMPTE274M (HD-SDI) / CVBS: 1.0Vp-p (75 ohm)
Min. IlluminationIR Product: 0 Lux at IR On
White BalanceAuto / Auto Ext / Preset / Manual
ShutterAuto / Manual (1/30sec ~ 1/60,000sec)
BrightnessAdjustable (0 ~ 20 Steps)
Sense UpOFF / × 2 / × 4 / × 8 / × 16 / × 32
DNROFF / Low / Middle / High
BacklightOFF / WDR / BLC / HLM
ACEOFF / Low / Middle / High
Day & NightAuto (Day <–> Night Time Change), Color, B/W, Extern
PrivacyOFF / ON
MotionOFF / SET
Digital Zoom×1 ~ × 16
FlipOFF / ON
FreezeOFF / ON
LanguageEnglish, Chinese, Chinese(S), Japanese, Korean
SharpnessAdjustable (0 ~ 10 Steps)
DefogOFF / SET
Communication PortRS-485 (Pelco-D)
Smart IRAdjustable (0 ~ 20 Steps)
Operating Temp / HumidityBetween 14°F (-10 °C) and 122°F (50 °C), with 30% to 80% relative humidity
Storage Temp / HumidityBetween -40°F (-40 °C) to 140°F (60 °C) with 20% to 90% relative humidity
PowerDC 12V
Signal TransmissionThe distance difference occurred according to cable option and other circumstances. (based on 5C-HFBT : HD-SDI (200M) / EX-SDI (400M))

Additional information

Weight4 lbs
Dimensions14 × 14 × 14 in
Color

Ivory, White
