UVST-KS4208

Eyemax UVST-KS4208 KS Series – 8 Chanel Octa-Brid DVR System. Supports EX-SDI,  HD-SDI, IP Camera, TVI, CVI, A-HD, 960H, Analog.

UVST-KS4208

Original price was: $239.99.Current price is: $219.99.

In stock

Original price was: $239.99.Current price is: $219.99.

Eyemax UVST-KS4208 8Ch HD-SDI TVI Security DVR

  • Autodetect Technology Connect cameras
  • 8Ch 1080p HDMI and spot out
  • H.264 Compression
  • Support for Mac and PC
  • OctaBrid SDI DVR
  • EX-SDI, HD-SDI, IP Camera, TVI, CVI, A-HD, 960H, Analog
  • Real-Time Display and Recording
  • iPhone and Android App (T DVR Viewer)
  • POS Interface Ready (4 Port USB to Serial)
  • Free DDNS Support (DDNS/ DynDNS / NO-IP/ zoneedit / freedns)
  • Alarm Input/Output 4 (NC/NO) / 1 (Relay)
  • 2 SATA (Up to 12 TB, 6 TB Each)
  • 4 Inputs (RCA) 1 Output (RCA)
Compare

Description

The Eyemax UVST-KS4208 Eyemax 8Ch HD-SDI TVI security DVR system provides excellent image quality and flexibility in CCTV surveillance. It can record audio and video in many formats, like EX-SDI, HD-SDI, IP Cameras, TVI, CVI, A-HD, 960H, and Analog. This powerful DVR also offers real-time display and recording, making it an ideal upgrade/replacement for older Magic DVR models.

The Eyemax UVST-KS4208 security DVR features four ports, four audio inputs, and one audio output. A free dynamic DNS service that includes support for DDNS, DynDNS, no-ip, zoneedit, and freedns.

In terms of setup, the Eyemax UVST-KS4208 Eyemax 8Ch HD-SDI TVI security DVR is incredibly easy to use. The device automatically detects your cameras, so you just need to connect them, and it takes care of the rest. An impressive 8-channel 1080p HDMI and spot output with H.264 compression are included in this DVR.

The Eyemax UVST-KS4208 Eyemax 8Ch HD-SDI TVI security DVR is easy to use and safe. You can watch and access your surveillance feed from anywhere. Users can stay connected and check out what’s happening in their home or workplace with the T DVR Viewer app.

People who want a sturdy and effective surveillance device will love the Eyemax 8Ch HD-SDI TVI security DVR. This DVR system is superb and has many useful features. It’s easy to set up and has an app for iOS or Android. You can replace your old Magic DVR or get a new security system with the Eyemax UVST-KS4208 security DVR.

Datasheet

Download

Eyemax UVST-KS4208 KS Series – 8 Chanel Octa-Brid DVR System. Supports EX-SDI, HD-SDI, IP Camera, TVI, CVI, A-HD, 960H, Analog Datasheet.

TypeEX-SDI Standalone DVR
CodecH.264 (Main Profile/High Profile)
Recording Performance160 FPS @ 1920 × 1080P
Playback Performance160 FPS @ 1920 × 1080p
Hardware
Video Input FormatEX-SDI 2.0 / HD-SDI / Analog CDs / 960H / SD
Video Input8CH
Video Output1 HDMI (Max. 1920 × 1080P), 1 VGA, 1 Composite
Audio Input4 Inputs (RCA)
Audio Output1 Output (RCA)
Audio CodecADPCM
Ethernet1 Port (10 / 100 Mbps / 1 Gbps Ethernet (RJ-45))
PTZ port1 Port (RS-485 Terminal Block)
POS/ATM4 Port (USB to serial)
Alarm Input / Output4 (NC/NO) / 1 (Relay)
USB Port4 Ports (2 Rear / 2 Front)
StorageUp to 2 SATA HDD
Software
Wizard SupportWizard for Easy Setup
ANS supportAuto-Network Setup Support
Recording SchedulingFully Programmable (by Weekday / by Hour / by Camera / by Continuous+ Event + Prevent)
NetworkDual Stream (User Selectable)
Recording Quality LevelBest / High / Moderate / Economic
Scheduling ModeContinuous / Alarm / Motion / Panic (Fully Programmable)
Pre-EventUp to 30 Minutes
Motion DetectionRegion Selection (Mouse dragging support)
Playback Speed×1, × 2, × 4, × 8, × 16, × 32, × 64, × 128
Backup FormatEXE (Self Executable Format), JPEG
Backup DevicesUSB
GUIUser Friendly Interface
Time ZoneYes
NTPYes
DDNSBuilt-in ddns / DynDNS / no-ip / zoneedit / freedns
Daylight SavingYes
Panic RecordingYes
Multi Language33 languages
CMSFull-Featured Enterprise Edition for Windows / Mac / Linux
Mobile Viewer iPhone / Android / iPad
Operating SystemEmbedded Linux
Dimensions(W × H × D)13.38 inches (33.99 cm) × 2.36 inch (5.99 cm) × 14.21 inch (36.09 cm)
Operating Temperature & Humidity41 °F (5 °C) ~ 104 °F (40 °C), 0% ~ 90%
PowerAdaptor
Power consumptionMAX 30W

Additional information

Weight10 lbs
Dimensions20 × 17 × 7 in
Hard Drive

No Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive, 10 TB Hard Drive, 12 TB Hard Drive

Hard Drive Slot 2

No Hard Drive Slot 2, 1 TB Hard Drive Slot 2, 2 TB Hard Drive Slot 2, 3 TB Hard Drive Slot 2, 4 TB Hard Drive Slot 2, 6 TB Hard Drive Slot 2, 8 TB Hard Drive Slot 2, 10 TB Hard Drive Slot 2, 12 TB Hard Drive Slot 2
