QNP-6230

Hanwha Vision WiseNet Q Series QNP-6230 2MP PTZ Network Dome Camera with 4.44-142.6mm Lens

QNP-6230

In stock
0 out of 5

Hanwha Vision WiseNet Q Series QNP-6230 2MP PTZ Network Dome Camera with 4.44-142.6mm Lens

  • Max. 2MP (1920 × 1080) resolution
  • 4.44 ~ 102.2mm (Optical 23x) lens
  • H.265, H.264, MJPEG codec support
  • Multiple streaming, WiseStream II support
  • Day and Night (ICR), WDR (120dB)
  • DIS with Built-in Gyro sensor
  • Tampering, Motion detection
  • Memory slot (Max. 256GB)
  • IP66, IK10
Hanwha Vision security cameras and video surveillance products at Collsam SecurityNDAA-compliant security products at Collsam Security

This product is no longer available.

Description

The Hanwha Vision WiseNet QNP-6230 Indoor PTZ Dome Camera is a high-quality surveillance camera that can be used indoors. This high-resolution camera boasts a 4.44-142.6mm lens, with Full HD (1080p) resolution at 30 frames per second. With its H.265, H.264, or MJPEG compression options, this camera delivers crystal-clear images while minimizing storage and bandwidth usage.

The 23x optical zoom lens on the WiseNet QNP-6230 allows for clear and detailed footage even at long distances. This makes it perfect for monitoring large indoor spaces such as warehouses, shopping malls, or public buildings. The camera can capture images in bright and dark areas without losing detail.

Hanwha’s WiseNet QNP-6230 features advanced noise reduction technology to ensure that video is clear without any graininess or distortion. Because the camera can move quickly and smoothly, no critical moment is missed.

The QNP-6230 offers versatile installation options, with both 24VAC power supply and PoE+ functionality available. This allows for easy integration into existing security systems. Furthermore, the camera has an SD/SDHC/SDXC card slot, enabling on-board storage for backup or standalone recording. With its compact and sleek design, this camera can be discreetly mounted on ceilings or walls, making it ideal for indoor spaces where aesthetics are important.

The Hanwha Vision WiseNet QNP-6230 is not just another surveillance camera – it’s a comprehensive security solution that delivers exceptional performance and peace of mind. With its powerful features, including 23x optical zoom, 120dB WDR, and true DNR, this camera provides detailed and reliable footage to ensure that every corner of your indoor space is under tight surveillance. Invest in the QNP-6230 today and experience the next level of indoor monitoring excellence.

Datasheet

Download

Hanwha Vision WiseNet Q Series QNP-6230 2MP PTZ Network Dome Camera with 4.44-142.6mm Lens Datasheet

Quick Guide

Download

Hanwha Vision WiseNet Q Series QNP-6230 2MP PTZ Network Dome Camera with 4.44-142.6mm Lens Quick Guide

User's Manual

Download

Hanwha Vision WiseNet Q Series QNP-6230 2MP PTZ Network Dome Camera with 4.44-142.6mm Lens User's Manual

Additional information

Weight5 lbs
Dimensions10 × 8 × 8 in

Brand

Hanwha Vision

Hanwha Vision provides professional video surveillance solutions for commercial, enterprise, government, retail, education, transportation, and other security applications. Its portfolio includes Wisenet security cameras, AI surveillance cameras, network video recorders, and video management software for modern security systems.Wisenet security cameras provide flexible monitoring options for indoor, outdoor, and specialized applications. AI surveillance cameras can support intelligent video analysis, object classification, and advanced event detection for demanding environments.Network video recorders provide centralized recording, storage, and management for compatible network cameras. Video management software gives security teams tools for live viewing, playback, search, system administration, and remote monitoring.Hanwha Vision solutions are available from Collsam Security for professional surveillance installations, system upgrades, and enterprise security projects.
Hanwha Vision security cameras and video surveillance products at Collsam Security

Professional Video Surveillance Solutions

Hanwha Vision develops professional surveillance technology for security systems ranging from individual sites to large multi-location environments. Its portfolio covers network cameras, recording equipment, video management, analytics, storage, and supporting technologies.

Network and AI Cameras

The camera portfolio includes dome, bullet, turret, PTZ, panoramic, multi-sensor, fisheye, thermal, and other specialized designs. Available technologies support high-resolution imaging, low-light monitoring, intelligent analytics, and flexible deployment for a wide range of applications.

Artificial Intelligence and Video Analytics

AI-based surveillance technology can help security teams identify important activity more efficiently. Depending on the selected equipment, intelligent functions can assist with object classification, event detection, search, and other analytical tasks.These capabilities can reduce the amount of video that operators need to review manually while improving awareness of essential security events.

Network Video Recording

Hanwha Vision provides network recording solutions for surveillance systems of different sizes. Recorder selection can be based on channel count, storage capacity, camera resolution, recording bandwidth, redundancy, and system-management requirements.Professional NVR solutions provide centralized storage and playback while supporting compatible network cameras and surveillance technologies.

Video Management and Monitoring

Video management technology gives operators a centralized environment for viewing cameras, reviewing recorded footage, managing events, and supervising larger surveillance systems.Flexible monitoring options can support individual workstations, security operations centers, and distributed environments with multiple locations.

Specialized Surveillance Applications

Advanced surveillance systems may require technologies such as panoramic imaging, thermal cameras, license plate recognition, multi-sensor cameras, or intelligent search capabilities.These specialized options allow integrators to design systems for applications where standard surveillance equipment may not provide sufficient coverage or analytical capability.

Hanwha Vision Solutions at Collsam Security

Collsam Security offers Hanwha Vision surveillance equipment for professional security applications. Customers can select cameras, recording systems, video management technologies, and related equipment according to the requirements of their security project.

NDAA

NDAA-compliant security products help organizations meet federal procurement requirements for covered telecommunications and video surveillance equipment. Section 889 of the FY2019 National Defense Authorization Act restricts federal procurement and contracting involving certain covered equipment and services. Collsam Security offers government security cameras, compliant NVRs, government security equipment, networking products, access control equipment, and surveillance accessories for professional applications. Government security cameras support federal, state, local, education, healthcare, transportation, and critical infrastructure surveillance projects. Compliant NVRs provide recording, storage, playback, and management for compatible IP camera systems. Government security equipment is available from Collsam Security for professional installations, system upgrades, and government-related security projects.
NDAA-compliant security products at Collsam Security
NDAA-Compliant Security SolutionsNDAA compliance is an important consideration for many federal, state, local government, education, transportation, healthcare, and critical infrastructure security projects.Section 889 RequirementsSection 889 restricts federal agencies from procuring or contracting for systems that use covered telecommunications equipment or services as a substantial or essential component, unless an applicable exception or waiver applies.NDAA-Compliant Security CamerasSecurity cameras identified as NDAA compliant can support government and commercial surveillance projects that require equipment sourced outside the covered categories addressed by Section 889.NDAA-Compliant NVRsNDAA-compliant network video recorders provide recording, storage, playback, and surveillance management for compatible IP camera systems.Government Security EquipmentGovernment security projects may require additional product documentation, manufacturer verification, contract clauses, and agency-specific procurement review.Professional Surveillance SystemsNDAA-compliant equipment can support surveillance systems for government buildings, schools, utilities, transportation facilities, healthcare locations, commercial properties, and critical infrastructure.NDAA Products at Collsam SecurityCollsam Security offers security products for customers seeking NDAA compliant surveillance and security solutions. Product eligibility should be confirmed for the specific procurement, contract, and agency requirements before purchase.
Video
Imaging Device1/2.8” CMOS
Resolution2592×1944, 2560×1440, 1920×1080, 1280×960, 1280×720, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360, 320×240
Max. Frame rate. H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 30fps (@5MP Max. 5fps)
Min. Illumination Color: 0.022Lux (F1.2, 1/30sec)
BW: 0.0022Lux (F1.2, 1/30sec, 30IRE), 0Lux(IR LED on)
Lens
Focal Length (Zoom Ratio)3.0mm fixed focal
Max. Aperture Ratio.F1.2
Angular Field of ViewH: 97° / V: 53° / D: 113°
Min. Object Distance. 2.0m(6.56ft)
Focus ControlFixed
Lens TypeFixed IRIS
Mount TypeM12
Pan / Tilt / Rotate
Pan / Tilt / Rotate Range0°~350° / 0°~75° / 0°~360°
Operational
Camera TitleDisplayed up to 85 characters
Day & NightAuto(ICR)
Backlight CompensationBLC, WDR, SSDR
Wide Dynamic Range120dB
Digital Noise ReductionSSNRⅤ, WiseNRⅡ(Based on AI engine)
Motion Detection8ea, 8point Polygonal zones
Privacy Masking32ea, 4point quadrangle zones
Gain ControlLow / Middle / High
White BalanceATW / AWC / Manual / Indoor / Outdoor
LDCSupport
Electronic Shutter Speed Minimum / Maximum / Anti flicker (1/5~1/12,000sec)
Video RotationFlip, Mirror, Hallway view(90°/270°)
Analytics                                                                 nClassified object type: Person/Vehicle (Type:car/bus/truck/motorcycle/bicycle) Attributes: Person, Vehicle (Type:car/bus/truck/motorcycle/bicycle)
Support DetectionShot
Analytics events based on AI engine
– Motion detection*, Object detection, Virtual line*(Crossing/Direction), Virtual area*(Loitering/Intrusion/Enter/Exit)
Analytics events
– Defocus detection, Tampering, Virtual area (Appear/Disappear)
* Some video analytics only works with people and vehicle detection
Business IntelligenceBased on AI engine: People counting, Vehicle counting, Queue management, Heatmap
Alarm TriggersAnalytics, Network disconnect
Alarm EventsWhen alarm trigger occurred
– File upload (image) : e-mail/FTP
– Notification : e-mail
– Recording : SD/SDHC/SDXC or NAS recording at event triggers
– Handover(PTZ preset, Send message by HTTP/HTTPS/TCP)
– Light alarm
Light TypeDual light (White warm light, IR)
IR Viewable LengthWhite LED :  30m(98.42ft) IR : 30m(98.42ft)
IR Wavelengthlong-life 850 nm IR LED
Network
Ethernet RJ-45 (10/100BASE-T)
Video Compression H.265/H.264: Main/High, MJPEG
Smart CodecManual(5ea area), WiseStreamⅢ(Based on AI engine)
Bitrate ControlH.264/H.265: CBR or VBR MJPEG: VBR
StreamingUnicast (20 users) / Multicast Multiple streaming (Up to 5 profiles)
ProtocolIPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP (TCP, UDP Unicast), MQTT
Application Programming InterfaceONVIF Profile S/G/T/M
Sunapi (HTTP API)
Security
OS / Firmware ProtectSecure boot, Signed firmware, Firmware encryption
User authenticationDigest Authentication, Prevent brute-force attack
Network authentication802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
Secure CommunicationHTTPS, SRTP, WSS(Websocket secure)
Access ControlAccess control based on IP address
Data ProtectAuthentication information encryption, ZIP compression encryption
AuditUser Access/System/Event log management
Device IDDevice Certificate (Hanwha Private Root CA)
Secure StorageSD card partition encrypt
General
Webpage Language English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Edge StorageMicro SD/SDHC/SDXC 1slot 256GB
Memory2GB RAM, 1GB Flash
Operating Temperature / Humidity -40°C~+60°C(-40°F~+140°F) / 0~95% RH
* Start up should be done at above -30°C Humidity control /w Air sheet
Storage Temperature / Humidity -50°C~+60°C(-58°F~+140°F) / 0~95% RH
CertificationIP66/IP67, IK10
Input Voltage PoE(IEEE802.3af, Class3)
Power ConsumptionPoE: Max 10.0W, typical 4.5W
Mechanical
Color / MaterialWhite / Aluminum
RAL Code RAL9003
Product Dimensions / Weightø 5.51 inch (14 cm) x 3.92 inch (9.96 cm), 1.74 lb (789.25 g)
Compatible Conduit hole / GangboxConduit hole : None
Gang box : Single, Double, 4″ Octagon
Hanging Mount (Dome)SBP-140HMW
Back boxSBV-140BW
Ceiling Mount (Assy) SBP-300CMW1/900CMW, SBP-150CMI/300CMI, SBP-300CMTW, SBP-300CMTS
Wall Mount SBP-140WMW, SBP-300WMW/WMW1, SBP-390WMW2
Pole MountSBD-140PMW, SBP-300PMW2, SBD-140PMB
Parapet MountSBP-300LMW, SBP-156LMW1
Corner MountSBP-300KMW1, SBD-140KMB
Tilt MountSBV-140TMW
CabinetSBP-300NBW
Certifications and Standards
EMCFCC 47 CFR 15 Subpart B Class A
ICES-3(A)/NMB-3(A) CE/UKCA
– EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3 VCCI CISPR 32 Class A
RCM AS/NZS CISPR 32 Class A
SafetyUL 62368-1, CAN/CSA C22.2 NO. 62368-1 IEC/EN 62471
EnvironmentIEC/EN 63000
IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK10
DORI (EN62676-4 standard)
Detect (25PPM/ 8PPF) 150.49ft (45.87 m)
Observe (63PPM/ 19PPF)60.19ft (18.35 m)
Recognize (125PPM/ 38PPF)30.09ft (9.17 m)
Identify (250PPM/ 76PPF)15.05ft (4.59 meters)
