SUL-10MLA

0 out of 5

( There are no reviews yet. )

Original price was: $379.99.Current price is: $229.95.

Luminys SUL-10MLA 8-Port LumiPower Unmanaged Megabit Switch (PoE++)

LumiPower technology extends power and data transmission via a single Ethernet cable up to 3,000 feet (914.4 m) without requiring repeaters. Ideal for simplifying installations in larger or more complex environments, LumiPower ensures consistent connectivity and dependable power management throughout security infrastructure.
Hardened: Features for harsh environments that protect the switch, connected devices, and data. These include a wide-operating temperature range, ruggedized construction with a metal enclosure and fanless convection cooling, DIN-rail mounting, redundant power inputs, reverse polarity surge, ESD protection, passive cooling and long MTBF.
SFP Uplink Port: Connect the switch to other network devices using fiber optics, depending on the type of SFP (Small Form-factor Pluggable) transceiver inserted. Supports both Single-Mode Fiber (SMF) and Multimode (MMF). SFP uplink port offers scalable, long-distance, and flexible high-speed connections for building robust and extendable networks.
LumiPower technology provides PoE up to 3,000 Feet to compatible LumiPower cameras / devices
Hardened: Protects Switch, Connected Devices, and Data
SFP Uplink Port provides connection to fiber for long-distance uplinks.
Supports PoE standards: IEEE802.3af, IEEE802.3at, and IEEE802.3bt.
Eight (8) LumiPower PoE Ports for Long-Range Transmission
Two (2) Gigabit Uplink Ports (One (1) SFP Port and One (1) RJ-45 Port)
Total PoE Power Budget: 120 W

Availability: In stock SKU: SUL-10MLA UPC: 810161161430 Categories: Network Switch, PoE Switches, Telephone and Networking Tags: 8-Port Unmanaged Switch, PoE, PoE (802.3af, PoE (IEEE 802.3af), PoE (IEEE802.3 BT), POE IEEE 802.3 AT and AF, Switch, Unmanaged POE Switch

Description

The Luminys SUL-10MLA is a high-quality 8-port network switch designed for use in security infrastructure and networking applications. This versatile device combines data and power transmission capabilities. This makes it a valuable asset in any system that requires Power over Ethernet (PoE) technology. With its compact and sleek design, the SUL-10MLA is an ideal choice for both small and large-scale installations.

One of the standout features of the SUL-10MLA is its support for various PoE standards, including IEEE 802.3af (PoE), 802.3at (PoE+), and the latest 802.3bt (PoE++) standard. This enables the switch to deliver up to 90 watts of power on some ports. It provides ample power for high-powered devices such as PTZ cameras and wireless access points.

With this level of power delivery, the SUL-10MLA eliminates the need for additional power sources or repeaters. Therefore, it provides a cost-effective and efficient solution.

The SUL-10MLA also boasts Luminys’ proprietary LumiPower technology, which extends the power and data transmission capabilities of the switch up to an impressive 3,000 feet (914.4 m). This is far beyond the standard 328 feet (100m) limit of most PoE switches. Thus, the SUL-10MLA is a top choice for long-distance installations.

This advanced technology is crucial for applications that require power transmission over extended distances. It does this without compromising on data transfer speeds.

Not only is the SUL-10MLA powerful and efficient, but it is also incredibly easy to use. As an unmanaged switch, it offers plug-and-play simplicity, allowing for quick and hassle-free installation. This feature is particularly beneficial for non-technical users or those without a dedicated IT team. With no complex configurations or settings to deal with, the Luminys POE Switch is a user-friendly and accessible choice.

The SUL-10MLA is also a “hardened” switch, meaning it is designed to withstand harsh environments. Its ruggedized construction, metal enclosure, fan-less cooling, and wide operating temperature range make it suitable for use in various settings, including outdoor installations. This durability and resilience make the Luminys POE Switch a reliable and long-lasting solution for security and surveillance systems.

Datasheet

Download

Upgrade your security infrastructure with Luminys SUL-10MLA, an 8-port unmanaged PoE switch with extended range and support for various PoE standards. Simplify installation and power management for your surveillance systems Datasheet.

User's Manual.

Download

Hardware
PoE Ports	Eight (8) 10/100Mbps PoE/PoE+/PoE++ Ports
Uplink Ports	One (1) 100/1000Mbps SFP Port One (1) 10/100/1000Mbps RJ-45 port
PoE Standards	IEEE802.3af, IEEE802.3at (PoE+), IEEE802.3bt (PoE++)
Network Standards	IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.3z
PoE Ports Power	Port 1 to 2: ≤ 90 W (PoE++) Ports 3 to 8: ≤ 30 W (PoE+)
Total Power Budget	120 W
PoE Pin Assignment	1, 2, 4, 5, (V+), 3, 6, 7, 8 (V-)
Performance
Switching Capacity	8.8 Gbps
Packet Forwarding Rate	5.36 Mpps
Packet Buffer Size	2.75 Mbit
MAC Table Size	8,000
MTBF	91.0 Years
Electrical
Power Supply	54 VDC, 2.22 A, External Power Supply
Power Consumption	Idle: 3.2 W Total: 120.0 W
Surge Protection	Power Port: 4 kV/2 kV Telecom Port: 8 kV
Construction
Net Weight	1.2 lb (0.54 kg)
Gross Weight	4.2 lb (1.91 kg)
Operating Temperature	-22°F (-30 °C) and 149°F (65 °C)
Operating Humidity	10% to 90% (RH), Non-Condensing
Product Dimensions (L× W × H)	5.9 inches (14.99 cm). × 4.4 inches (11.18 cm). × 1.7 inches (4.32 cm)
Casing Material	Metal
Certifications and Compliance
Certifications	FCC Part 15 Subpart B NDAA Complaint

Additional information

Weight	6 lbs
Dimensions	10 × 8 × 10 in
