DC-612V
Original price was: $138.99.$88.95Current price is: $88.95.
PRIME® DC-612V 650TVL Dome Camera with Auto-Iris Varifocal Lens
- HERO DSP Chipset Ensures High-Quality 650TVL Image
- 2.8~12 mm Auto-Iris Varifocal Lens
- 1/3” Sony Super HAD II CCD Image Sensor
- 3-Axis Construction
- True Day or Night (ICR)
- Single Scan WDR
- 3DDNR Noise Reduction
- High Light Masking (HLM) Ensures Clear Images in High Light Areas
- On Screen Display (OSD) Camera Setup
- DC 12V Power
- Description
- Product Documents
- Specifications
- Additional information
- Collsam Brands
- Reviews (0)
Description
The PRIME® DC-612V Dome Camera is the perfect surveillance camera choice for any situation. This camera is equipped with 650TVL 1/3” Sony Super HAD II CCD HERO DSP Chipset and 2.8~12 mm Auto-Iris Varifocal Lens. It also features 3-Axis construction for easy installation in various locations.
The PRIME® DC-612V Dome Camera offers True Day and Night (ICR) Single Scan and Wide Dynamic Range (WDR) for clear images in any lighting condition. It features 3DDNR (3D Digital Noise Reduction) for enhanced image clarity and SENS-UP for efficient image capture in low-light conditions. Additionally, the HLM (High Light Masking) technology ensures that bright spots and overexposure are automatically adjusted.
This camera allows you to customize your image settings with the convenient OSD CAMERA SETUP. You can adjust the brightness, contrast, hue, and more with just a few clicks. The PRIME® DC-612V Dome Camera is also powered by DC 12V for added convenience.
The PRIME® DC-612V Dome Camera is a reliable and durable surveillance camera that is built to last. With this camera, you can have peace of mind knowing that your security is always secured. Thanks to its advanced features and superior image quality, you can monitor your premises with confidence.
The PRIME® DC-612V Dome Camera is the perfect choice for any surveillance system. Thanks to its high-quality image capture, superior construction, and convenient setup, you can rest assured that your surveillance needs are met with ease. Don’t settle for anything less than the best; choose the PRIME® DC-612V Dome Camera for your security needs.
| Resolution | 650 TV Lines |
| Sensor | 1/3 inch SONY Super HAD II CCD |
| Total Pixels | 811(H) × 508(V) 410K pixels (NTSC) |
| Effective Pixels | 768(H) × 494(V) 380K pixels (NTSC) |
| Scanning System | 2:1 Interlace |
| S/N (Y signal) | More than 50dB (AGC off) |
| Frequency | Horizontal : 15.734KHz / Vertical : 59.94Hz (NTSC) |
| Video Output | CVBS : 1.0Vp-p / 75ohm |
| Min. Illumination | 0.1 Lux at F1.2 / 0.0001 Lux (Sens-up × 256) |
| White Balance | ATW / AWC / Push / Manual Adjustable |
| Electronic Shutter Speed | Auto / Manual (1/60 sec ~ 1/100,000 sec) (NTSC) |
| OSD | Built-in |
| Backlight Compensation | Low / Middle / High / Off Selectable |
| Gain Control | Low / Middle / High / Off Selectable |
| 3D DNR | Low / Middle / High / Off Selectable |
| WDR (Wide Dynamic Range) | On / Off |
| Sens-up | x2 ~ × 256 / Off |
| Day and Night | Auto / Color / Black and Weight / CDS |
| Motion Detection | ON / OFF (240 Zone) |
| Privacy Mask | ON / OFF (6 Zone) |
| Image Conversion | Freeze / Vertical or Horizontal Flip / Rotate / Negative: All ON/OFF adjustable |
| Digital Zoom | ON (× 10) / OFF |
| Operating Temperature / Humidity | 14 °F (-10 °C) ~ 122 °F (50 °C)) / 30% ~ 80% RH |
| Storage Temperature / Humidity | -4 °F (-20 °C) ~ 140 °F (60 °C)) / 20% ~ 90% RH |
| Power Source | DC 12V |
Additional information
| Weight | 2 lbs |
|---|---|
| Dimensions | 8 × 8 × 8 in |
