UIU-MP4132V
Price range: $125.95 through $126.95
Eyemax UIU-MP4132V 4MP EX-SDI Turret Camera
- 4MP 1440p video at 30 fps
- 2.8–12 mm motorized varifocal lens
- 20 IR LEDs with a 50 ft (ca. 15 m) night range
- WDR, DNR, Smart IR, motion detection, and defog
- IP67-rated outdoor turret housing
- 12V DC power with white or gray options
- Description
- Technical Specifications
- Product Resources
- Additional Information
- Collsam Brands
Description
Designed for dependable IP67 infrared turret camera surveillance over coaxial infrastructure, the Eyemax UIU-MP4132V 4MP security camera uses its motorized varifocal turret camera to deliver detailed 1440p video without network conversion. Its Sony IMX-335 CMOS sensor records up to 30 fps, helping operators follow movement smoothly across entrances, parking areas, retail spaces, and office corridors.
The integrated 2.8–12 mm motorized lens gives installers control over scene coverage. A wide setting monitors a larger area, while a tighter setting brings a doorway, register, or access point closer. Therefore, the motorized varifocal turret camera can be adjusted, reducing the time needed to fine-tune the view.
Furthermore, 20 infrared LEDs support night monitoring with a rated range of 50 feet (ca. 15 m). Smart IR manages illumination when people approach the MP4132V turret camera, which helps prevent faces or objects from appearing overly bright. Meanwhile, day-and-night operation changes between color and monochrome imaging as light falls.
This 4MP EX-SDI turret camera also provides WDR, DNR, BLC, HLC, defog, privacy masking, motion detection, image flip, sharpness, and brightness controls. As a result, technicians can improve visibility in backlit entrances, hazy scenes, or locations with uneven lighting. The UIU MP4132V camera provides a CVBS service output for setup and testing.
Built as an IP67 infrared turret camera, the housing resists dust and weather. Its turret form supports discreet placement beneath eaves, on walls, or across entry points. It operates on 12V DC power and is offered in white or gray to suit installations.
The UIU-MP4132V 4MP security camera includes automatic, preset, and manual white-balance options. In addition, its electronic shutter supports automatic control or manual adjustment from 1/30 to 1/30,000 second. Collsam Distribution offers this Eyemax UIU-MP4132V turret camera for projects needing reliable EX-SDI performance, flexible zoom, and clear infrared coverage.
| Resolution | 1440P |
| Lens | Motorized Varifocal Lens 2.8~12mm |
| Sensor | 1/2.8-inch SONY® CMOS (IMX-335) |
| Pixels | Total : 2704(H) × 2104(V) = 5.69M / Effective : 2616(H) × 1964(V) = 5.14M |
| Scanning System | PROGRESSIVE |
| S/N (Y signal) | More than 52 dB (AGC Off) |
| Video Output | SMPTE274M EX-SDI (CVBS) |
| Frame Rate | 4MP@30fps |
| Min.Illumination | 0 Lux at IR On (IR LED 20) |
| White Balance | Auto / Auto Ext / Preset / Manual |
| Electronic shutter speed | AUTO / MANUAL (1/30sec ~ 1/30,000sec) / FLICKER |
| Function | DNR / ACE / WDR / BLC / HLC / Sens_up / Privacy / Flip / Motion / Defog / RS-485 / Sharpness / Smart IR / Brightness |
| Day and Night | AUTO (Day <–> Night TIME Change), COLOR, Black and White, EXTERN |
| Language | ENG, CHN, CHN(S), JPN, KOR |
| IR Distance | 15M |
| Temperature/Humidity | Operating 14°F (-10 °C) ~ 122°F (50°C) / 30% ~ 80% RH Storage: -4°F (-20 °C) ~ 140°F (60°C) / 20% ~ 90% RH |
| Power | DC 12V |
| Dimensions | ∅ 4.09 inch (10.39 cm)× 3.54 inch (8.99 cm) |
| Signal Transmission | The distant difference is occurred according to the cable option and other circumstances. |
Additional information
| Weight | 3 lbs |
|---|---|
| Dimensions | 7 × 7 × 7 in |
| Color | Gray, White |
Brand
Eyemax
