TVST-PVT3-04N5

Eyemax TVST-PVT3-04N5 4Channel Pentabrid DVR. Supports up to 5MP cameras and offers advanced features like digital zoom, PTZ control, Up to 12 Terabytes Hard Drive and multiuser authority.

TVST-PVT3-04N5

In stock
0 out of 5

Eyemax TVST-PVT3-04N5 4-Channel Penta-Brid CCTV DVR System Support for HD-TVI, HD-CVI, HD-AHD, 960H Analog Cameras

  • Full GUI with alpha blending
  • Individual setting of resolution, frame rates and picture quality
  • Instant Replay
  • Digital Zoom
  • Mouse Control
  • Weekly scheduler with holiday by 10 minutes setting
  • Covert, Disable and Private function of cameras
  • Motion Detection with 576 area setting
  • Relay alarm output
  • PTZ control by RS-485
  • Daylight Saving Time and Network Time Setting
  • Multi-User Authority up to 8 Users
  • Deinterlacer upon live and playback
  • 22 languages with full graphic
  • Individual Network port setting
  • Auto Deletion
  • Import and Export the configuration
  • Interactive setup via network
  • POS Interface
  • No Mirroring
  • Dual CODEC engine for independent video transmission
Eyemax security cameras and video surveillance products at Collsam SecurityNDAA-compliant security products at Collsam Security
Recomanded Replaceable Product!
SKU: TVST-PVT3-04N5 Categories: , Tags: , , , , , , , , , , , ,
This product has been discontinued

Description

The Eyemax TVST-PVT3-04N5 is a top-of-the-line surveillance system that offers unparalleled flexibility and security for any surveillance operation. This DVR system has 4 channels and a high-quality camera that can take clear pictures and keep track of things. With its H.265 compression technology, this system can store more footage without using as much space.

The Eyemax TVST-PVT3-04N5’s Penta-brid technology makes it possible to connect numerous cameras to it. This includes traditional analog cameras, as well as the more advanced HD-TVI, AHD, CVI, and IP cameras. The Eyemax TVST-PVT3-04N5 is a great way to upgrade your surveillance system without having to buy a new DVR.

There is ample storage for all your surveillance footage provided by the Eyemax TVST-PVT3-04N5 with 1 x SATA port. You can record for longer periods of time without having to constantly delete old footage. With its advanced motion detection capabilities, the Eyemax TVST-PVT3-04N5 can detect any unusual activity and immediately alert users in real-time.

This feature is crucial for proactive security measures, as it allows for prompt intervention and resolution of any potential threats.

The TVST-04N5 was made to last a long time. Its compact size also makes it easy to install and conceal, providing discreet monitoring without sacrificing reliability. The system also comes with a user-friendly interface, making it easy for even non-technical users to navigate and configure settings.

The Eyemax TVST-PVT3-04N5 4-channel 3MP H.265 Penta-brid DVR system is the best choice for any surveillance operation. This system is great for businesses and people who care about keeping their things safe and secure. It has great recording quality, uses Penta-brid technology, can detect movement well, and is very sturdy.

Use the Eyemax TVST-PVT3-04N5 to keep an eye on your house or business and feel safe knowing it’s reliable and effective.

Video
Camera input4 BNC
Individual HD/Analog selectableAnalog / TVI / AHD / CVI / IP
Available sourceTVI / AHD / CVI 720p@25/30
1080p@25/30
3MP@18
4MLite@12~30/
Composite / 960H / Mixed
IP Camera SpecONVIF 1812, RTSP, H.264, H.265, dual stream
use gigabit Ethernet hub
IP Camera1
IP Camera Resolutionup to 3M
IP Camera RestrictionCannot set up a Private ZONE
Cannot support Timestamp
Output1 HDMI (Main Display, ~4M@30)
1 VGA (Main Display, ~1080P60)
1 Composite (Programmable SPOT)
Audio
Audio input4 RCA
Output1 RCA
Sensor In4 (NC, NO selectable)
Alarm out1 relay
Operating SystemEmbedded Linux OS
Display
SpeedReal Time
Resolution (Pixel)1280 × 1024 / 1280 × 720 / 1920 × 1080
Split screen1 / 4
Main Recording
CODECH.264 / H.265
Resolution (Pixel)2,3MP or 720p @ 2,3MP input
720p or 960 × 540 @ 720p input
960H or D1 @ Composite / 960H input
Picture quality4 steps (Super, High, Medium, Low)
Speed60fps @ 1080p
Dual Recording
CODECH.264 / H.265
Resolution (Pixel)512 × 320
Playback
Display1 / 4
Search modeCalendar / Event / POS / Thumbnail / Bookmark
Speed30fps @ 1080p
Fast/Slow speedNormal / REW & FF (recorded speed ×2 / ×4 / ×8 / ×16 / ×32 / ×64 / ×1/2 ×1/4) / Frame to frame / Pause
Network (Individual setting of resolution, frame rates and picture quality)
Network InterfaceMegabit Ethernet
ProtocolTCP/IP / HTTP / DHCP
ApplicationWindows 7 / 8 / 10 (PC Client System & I.E.,) / MAC
Web BrowserInternet Explorer
Smartphone AppAndroid, iPhone for live and search
Backup
InterfaceUSB 2.0 × 2
Backup deviceExternal HDD and CD/DVD-RW / Network / Thumb Drive
The number of HDD1 SATA(No capacity limit ; 10 TB or more)
MirroringNo
Others
Power Consumption24W
Operating Temperature32 °F (0°C) ~ 104 °F (40 °C)
Relative HumidityMaximum 80% non-condensing
Dimension11.8 inches (29.97 cm)(W) × 8.27 inches (21.01 cm) (D) × 1.89 inches (4.8 cm) (H)

Additional information

Weight8 lbs
Dimensions20 × 12 × 9 in
Hard Drive

No Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive, 10 TB Hard Drive, 12 TB Hard Drive
