IP-5PT4IEN8-4X

Upgrade your surveillance game with ENS IP-5PT4IEN8-4X, a 4MP mini PTZ camera from ENS Security's Titanium series. With 4x zoom, AI-based detection, and two-way audio, this compact camera is perfect for outdoor use. NDAA compliant and packed with advanced features.

IP-5PT4IEN8-4X

Original price was: $582.00.Current price is: $348.40.

In stock

Original price was: $582.00.Current price is: $348.40.

ENS IP-5PT4IEN8-4X IPC 4 Megapixels, PTZ, 2.8-12 mm motorized

  • Progressive scan BSI+NIR image sensor
  • Up to 2560×1440 resolution
  • Mini illumination:
    • Color: 0.01 lux @ (F1.6 AGC ON)
    • 0 Lux with IR
  • 4x optical zoom, fast and accurate
  • Smart IR up to 50m, 2 White LEDs 30m
  • Bi-directional audio, built-in Mics &Speaker
  • 30m for audible warnings,7m for voice recording
  • AI-based human vehicle detection &classification and
  • tracking, perimeter precaution, cross line, etc.
  • SD/TF card chamber, Reset button, Alarm in/out
  • PoE+ or DC12V power supply, easy installation
  • IP66 Water-proof, IK10
  • ONVIF, API,SDK,IE/NVR/VMS/free mobile Apps
ENS Security cameras and video surveillance products at Collsam SecurityNDAA-compliant security products at Collsam Security

Description

The ENS IP-5PT4IEN8-4X is the ultimate solution for all of your surveillance needs. Manufactured by ENS Security, a trusted brand in the industry, this mini PTZ (Pan-Tilt-Zoom) camera is part of their Titanium series of surveillance products. With its impressive 4 megapixel (2560×1440) resolution at 30 frames per second, you can be assured that every detail will be captured with crystal clarity.

One of the standout features of this camera is its 2.8-12mm motorized varifocal lens with 4x optical zoom. This allows you to zoom in on specific areas of interest and maintain high-quality images without any loss of detail.

Moreover, the camera has both white and infrared (IR) LEDs. It provides up to 164ft (49.99 m) IR distance and a full-color option in low-light conditions. This means you can capture clear footage even in the darkest of environments.

The ENS IP-5PT4IEN8-4X also comes with a built-in microphone and speaker, allowing for two-way audio communication. This not only facilitates remote monitoring, but also serves as a powerful active deterrence tool with audible warnings. Furthermore, the camera supports AI-based human/vehicle detection and classification, auto-tracking, and perimeter protection (crossing line, etc.). This makes it a highly intelligent surveillance solution.

This camera is designed with convenience in mind, as it can be powered by either Power over Ethernet (PoE+) or a DC12V power supply. It also comes with an SD card slot and alarm I/O ports, allowing for easy storage and integration with other security systems. The camera is also IP66 waterproof and IK10 vandal-proof rated. This makes it suitable for outdoor use in any weather conditions.

What’s more, it is NDAA compliant, ensuring that it meets the highest standards of security and quality.

With its impressive resolution, powerful zoom capabilities, and intelligent features, this camera is a must-have for any surveillance setup. Trust ENS Security and choose the ENS IP-5PT4IEN8-4X for all of your security needs.

Camera
Image Sensor1/2.5” 4MP progressive scan BSI/NIR
Image Resolution2592 (H) × 1944 (V)
Electronic Shutter50 Hz: 1/25 s ~ 1/25,000 s
60 Hz: 1/30 s ~ 1/30,000 s
Minimum Illumination0.01 lux @ F1.6, AGC ON (Color)
0.002 lux @ F1.6, AGC ON (B/W)
0 lux with IR
Smart IRN/A
S/N Ratio≥ 52 dB
IR Distance151 ft (46.02 m)
Lens TypeFocal lens
Iris TypeN/A
Focal Length2.8 ~ 12 mm
Optical Zoom
Angle of ViewHorizontal: 97° ~ 31° ±5%
Vertical: 51° ~ 18° ±5%
Diagonal: 115° ~ 36° ±5%
Max. ApertureF1.6
Pan / Tilt / RotationPan: 0° ~ 355°; Tilt: -5° ~ 90°; Rotation: N/A
Compression Standards
Video CompressionH.265+ / H.264+ / H.265 / H.264 / MJPEG
Streaming Capability3 Streams
Video Frame RateMain Stream:
2560×1440, 2048×1536, 1920×1080,
1280×960, 1280×720 @ 25/30 fps
Sub Stream:
704×576, 640×480, 352×288 @ 25 fps
704×480, 640×480, 352×240 @ 30 fps
Third Stream:
1280×720, 704×576, 640×480, 352×288 @ 25 fps
1280×720, 704×480, 640×480, 352×240 @ 25 fps
Video Resolution (Max.)4M (2560 × 1440)
Video Bitrate64 Kbps ~ 16 Mbps
Video Bitrate TypeVBR / CBR
Image and Feature Support
Wide Dynamic Range120 dB true WDR
BLC ModeYes
HLC ModeYes
White BalanceAuto / Manual / Indoor / Outdoor
Day / NightAuto / Manual
Gain ControlAuto / Manual
Digital Noise Reduction3D DNR
Motion DetectionYes
Electronic Image StabilizationN/A
DefogYes
Digital ZoomN/A
FlipN/A
MirrorN/A
Privacy Masking4
Image RotationN/A
ROIN/A
Picture OverlayLogo picture could be overlaid on the video with 128×128 pixels, 24bits BMP format
Font OverlayMax. 15 characters per line, 8 lines max, white color or red color
Image SettingsFlip, Mirror, Saturation, Brightness, Contrast, Sharpness, AGC, and AWB adjusted by client
IPC AlarmN/A
Alarm Input1
Alarm Output1
Audio CompressionG.711 A/U
Intelligent and Functions
Basic EventMotion detection, video tampering alarm, exception (network disconnected, IP address conflict, SD full, SD error)
Face RecognizeSupport human face detection, max 15 human faces per scene. Support face capture, tracking, comparison, and edge storage.
Road TrafficVehicle detecting and tracking, etc.
Smart DetectionTripwire, Bi-directional tripwire, Illegal intrusion detection, Region entrance detection, Region exiting detection, Unattended baggage detection, Object removal detection, etc.
Smart TrackingSmart tracking of human or vehicle, auto/manual
Active DeterrenceFlash strong white light and a predefined voice upon invaders being detected. Support predefined voice.
Two-Way TalkYes
Network and Interface
EthernetRJ-45 (10/100 Adaptive Ethernet), support PoE+
Network ProtocolHTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP,DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP,DHCP, PPPoE
Network InteroperabilityONVIF
Streaming MethodN/A
Network Max. Users16
StorageBuilt-in Micro SD Card (supports max. 256 GB)
Video OutputN/A
General FunctionWatermark, IP address filtering, video mask, heartbeat, password protection, image distortion correction
Audio Interface1/1
Built-in MicYes
Built-in SpeakerYes
RS485Yes
RS232Yes
Reset ButtonYes
Heater and FanOne electrical heater, no fan
Water RemovalDust and Water-resistant coating for lens cover
General
Power SupplyDC 12 V / PoE+ (802.3.at, class 3)
Power ConsumptionAVG. 4.5 W; Max. 24.5 W ( IR/White LED, Speaker ON, PT Rotation)
Operating Temperature-22°F (-30°C) ~ 131 °F (55 °C)/ Less than 90% RH
Storage Temperature-40 °F (-40°C) ~ 149 °F (65 °C) / Less than 95% RH
ProtectionIP66, IK10
CasingAluminum Alloy
Dimensions6.4 inches (16.26 cm) × ø 5.1 inches (12.95 cm)
Net WeightApprox. 2.645 lbs.
InstallationCeiling mounting; Wall mounting
CertificateROHS, CE, FC, 3C

Additional information

Weight4 lbs
Dimensions7 × 7 × 8 in

Brand

ENS Security
