NVST-TS6128A
Eyemax NVST-TS6128A NVR. NDAA compliant, 128 channels, RAID protection, advanced analytics.
- Support 128CH 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF IP input
- H.265S/H.265+/H.265/H.264 coding
- Intuitive and user-friendly Graphic User Interface (GUI), Windows-style operation by mouse
- Multi-mode recording: manual/timed/motion/sensor/POS/AI recording
- Playback: 16 CH simultaneous playback
- Search: time slice, time, event, tag, smart, and target database search
- Support face detection and comparison
- Support multiple VCA (Video Content Analytics) events, such as region intrusion, tripwire, etc.
- Support OS information overlay on live view and playback
- Support RAID 0, 1, 5, 6, 10
- Express and flexible backup via USB, network, and so on
- Preview, record, playback, backup, and remote access are supported
- DHCP, DDNS, PPPoE network protocol, etc.
- Compatible with third-party IPCs, such as ONVIF, Hikvision, etc.
- Remote control via Web Client or CMS: preview, playback, backup, PTZ and configuration
- Multi-user online simultaneously
- Authorization management, log view, and device status view
- 8K output, true high-resolution display
- Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
- Support NAT function and QR code scanning by mobile phones
- Powerful mobile surveillance by smartphones with iOS and Android OS
SKU: NVST-TS6128A
Categories: 128 Channel Network Video Recorders NVRs, Network Video Recorders NVRs
Tags: Face detection, H.265S/H.265+/H.265/H.264 coding, NDAA Compliant;, Network IP PTZ, RAID 0/1/5/6/10, VCA AI Search- Description
- Attachment
- Specifications
- Additional information
- Reviews (0)
Description
The Eyemax NVST-TS6128A is a top-of-the-line, enterprise-grade 128-channel network video recorder (NVR) designed for large-scale security systems. Part of the IP Power 6000 Series, this NVR is fully compliant with the National Defense Authorization Act (NDAA). This makes it a reliable and secure choice for government and commercial use. Built to handle massive bandwidth and ensure robust data redundancy, the Eyemax NVST-TS6128A is a powerful solution for high-density IP surveillance.
This NVR supports up to 128 IP cameras simultaneously, with an impressive incoming and outgoing bandwidth of 768 Mbps. It also offers support for recording and previewing up to 16 Megapixels (MP). This makes it ideal for high-resolution surveillance.
The Eyemax NVST-TS6128A is designed for flexibility, with support for H.265 / H.265+ / H.265S / H.264 legacy formats. This allows it to work with a wide range of cameras. It also features 4 HDMI ports, each supporting up to 8K resolution output. Additionally, it comes with 1 VGA port for added convenience.
For storage scaling, the Eyemax NVST-TS6128A accommodates 16 internal SATA hard drives and 2 external eSATA connections. It also comes with an out-of-the-box hardware configuration for RAID 0, 1, 5, 6, and 10. This provides added protection against drive failure. This allows you to store a large amount of footage without worrying about losing important data.
In addition to its impressive technical capabilities, the Eyemax NVST-TS6128A also offers advanced features for enhanced security. It supports face detection and comparison, which can be configured via 128-channel IPC-side analytics or up to 4 channels natively on the NVR. This NVR also offers human, vehicle, and license plate recognition (LPR) event classification. As a result, it is easier to identify and track potential threats.
The Eyemax NVST-TS6128A also features video content analytics, including region intrusion detection, tripwire boundary violations, and fisheye lens dewarping support. These smart features allow for more efficient and accurate surveillance, providing you with greater peace of mind.
Overall, the Eyemax NVST-TS6128A is a top-notch, intelligent NVR that offers high-performance and optimal security for demanding enterprise-level applications.
| System | |
|---|---|
| OS | Embedded Linux |
| Video | |
| IP Video Input | 128CH |
| Network Bandwidth | Incoming: 768 Mbps Outgoing: 768Mbps |
| Resolution | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280 × 1024/960P/720P/960H/D1/CIF |
| Output | HDMI1: 7680 × 4320@60, 7680 × 4320@30, 3840 × 2160@60, 3840 × 2160@30, 1920 × 1080, 1280 × 1024, 1024 × 768 (When the resolution of HDMI1 output is 8K, HDMI2 is unavailable.) HDMI2: 3840 × 2160@60, 3840 × 2160@30, 1920 × 1080, 1280 × 1024, 1024 × 768 HDMI3: 3840 × 2160@60, 3840 × 2160@30, 1920 × 1080, 1280 × 1024, 1024 × 768 HDMI4: 1920 × 1080, 1280 × 1024, 1024 × 768 VGA × 1: 1920 × 1080, 1280 × 1024, 1024 × 768 (VGA and HDMI1 output the same video source) |
| Multi-screen Display | Main output: 1/4/6/8/9/13/16/25/32/36/64 AUX output 1: 1/4/6/8/9/13/16/25/32/36 AUX output 2: 1/4/6/8/9/13/16 Aux output 3: 1/4/6/8/9/13/16 Max. 132 (64+36+16+16) |
| Compression | H.264/H.265/H.265+/H.265S |
| Audio | |
| Network input | 128CH |
| Local Input | RCA×1 (for two-way talk) |
| Local Output | RCA×1 |
| HDMI Audio Output | Support |
| Compression | G.711(U/A) |
| Record | |
| Resolution | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280 × 1024/960P/720P/960H/D1/CIF |
| Frame Rate | <imgheight=”11″ src=”file:///Macintosh HD/Users/media/Library/Application Support/Adobe/Dreamweaver 2021/en_US/OfficeImageTemp/clip_image001.png”>N:30fps; P:25fps</imgheight=”11″> |
| Playback | |
| Simultaneous Playback | 16CH |
| Search | Time slice/time/event/tag/smart search |
| Function | Play, pause, FF, rewind, digital zoom, previous frame, next frame, etc. |
| Decoding Capability | |
| Live View | 1CH 16MP@30 / 4 CH 12MP (only available for main output) |
| Playback | 1CH 16MP@30 / 4CH 8MP (only available for main output) |
| Alarm | |
| Mode | Manual, sensor, motion, exception, smart events, etc. |
| Input | 24CH |
| Output | 8CH |
| Triggering | Record, snapshot, preset, e-mail, etc. |
| Face | |
| Face Detection Performance (AI by IPC) | 128CH |
| Face Detection Performance (AI by Device) | 4CH |
| Face Match Performance | 16CH |
| Comparison Capability | 36 pictures/second |
| Face Picture Database | 32 libraries 10000 face pictures |
| Face Picture Search | Search by picture is supported |
| Database Management | Add, modify, delete, and search face pictures |
| Face Picture Adding | Add face pictures through APP, WEB, and external import |
| Face Picture Comparison | Supports successful face recognition alarm and stranger match alarm |
| Track | Track display on a map |
| Statistical Graph of Information | Bar graph |
| Statistical Mode of Information | Statistics by day, week, month, and quarter, as well as customized time |
| Video Structure Analysis | |
| Human/Vehicle Classification (AI by IPC) | 128CH |
| Human/Vehicle Classification (AI by Device) | 8CH |
| Human/Vehicle Attribute Analysis | Yes |
| Other Functions | |
| Fisheye | Supports fisheye dewarping via NVR/Web Client/mobile APP |
| Plate Recognition (AI by IPC) | Yes |
| Network | |
| Protocol | TCP/IP, HTTP, HTTPS, 802.1x, FTP, DHCP, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IPv6, UDP, WebSocket, PPPoE, SNMP, IGMP |
| Interface | RJ45 10/100/1000Mbps × 2 |
| Client Connection | Max. 128 users access |
| Mobile Device | |
| OS | iOS, Andriod |
| Storage | |
| HDD Interface | SATA×16 max 10TB per HDD |
| RAID Type | RAID 0, 1, 5, 6, 10 |
| E-SATA Interface | 2 |
| Port | |
| USB | USB 3.0 × 1, USB 2.0 × 3(Front:2) |
| RS485 | Yes (full-duplex), connect to PTZ or keyboard |
| RS232 | Yes |
| Reset | Yes |
| Remote Controller | No |
| Others | |
| Power | ATX-275W |
| Consumption | ≤50W (without HDD) |
| Dimensions | CE, FCC |
| Certificate | |
| Environmental Protection | Directive EU RoHS, WEEE (2012/19/EU), Directive 94/62/EC, and REACH (EC1907/2006) |
| Working Environment | 14°F (-10°C) ~ 122°F (50°C); Humidity: 10% ~ 90% |
Additional information
| Weight | 35 lbs |
|---|---|
| Dimensions | 21 × 21 × 7 in |
| Hard Drive | No Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive, 10 TB Hard Drive, 12 TB Hard Drive, 14 TB Hard Drive, 16 TB Hard Drive, 18 TB Hard Drive, 20 TB Hard Drive, 22 TB Hard Drive, 24 TB Hard Drive, 36 TB Hard Drive, 56 TB Hard Drive, 64 TB Hard Drive, 72 TB Hard Drive, 88 TB Hard Drive, 96 TB Hard Drive, 112 TB Hard Drive, 128 TB hard Drive, 140 TB Hard Drive, 150 TB Hard Drive, 160 TB Hard Drive |
