NVST-TX208-32

Eyemax NVST-TX208-32 NVR. High Resolution 32 Channel NVR with PoE Input and SOC Technology Perfect for home, commerce, and government security needs.

NVST-TX208-32

$128.95$639.95

In stock

$128.95$639.95

Eyemax NVST-TX208-32 32 Channel Network Video Recorder(NVR) for IP cameras up to 3MP with 8 Channel PoE Input

  • Support 32 channels 3 MP@30fps or 1080P@30fps or 960P@30fps or 720P@30fps IP input
  • Intuitive and user-friendly Graphic User Interface (GUI), Windows style operation by mouse
  • Multi-mode recording: manual
    • timer
    • motion
    • sensor
  • Playback : support 16 Channel playback
  • Search
    • calendar
    • time, events
    • sensor
    • motion
  • Express and flexible backup via USB, network or DVD-RW
  • Pentaplex preview, record, playback, backup and remote access
  • DHCP, DDNS, PPPoE network protocol and CMS supported
  • Remote control via IE or CMS : preview, playback, backup, PTZ and configuration
  • Dual streaming technology to encode recording stream & network stream separately.
  • User can adjust network stream to fit bandwidth without changing recording quality.
  • Multi-user online simultaneously
  • HDMI 1080P output, true high-resolution display
  • Support PTZ preset and auto-cruise, up to 128 presets & 8 cruises
  • Powerful smartphone surveillance supporting iPhone, Android. Compatible with 3G

Compare

Description

The Eyemax NVST-TX208-32 is a high-quality Network Video Recorder (NVR) that is perfect for all your security needs. This new NVR uses a special technique called SOC to make sure each channel has clear video. With its robust system and H.264 compression, the Eyemax NVST-TX208-32 offers superior performance and reliability.

This NVR is equipped with 32 channels of IP input, allowing you to connect numerous cameras for comprehensive surveillance. It supports real-time 3Megapixel, 1080P, 960P, 720P, and D1 high-resolution recording, ensuring that every detail is captured with precision. With the 16 channel playback feature, you can watch footage from multiple cameras at once. This makes it easier and more effective to keep an eye on your place.

The Eyemax NVST-TX208-32 also boasts an HDMI 1080P high-resolution display, providing you with crisp and clear video output. It’s a powerful and compact gadget that fits right into any security setup thanks to its 1U chassis. The Eyemax is the perfect solution for your home, financial institution or business.

Collsam Security is proud to offer this advanced NVR from Eyemax, ensuring that you have access to top-of-the-line security products. Our company is a reliable source for all Eyemax products, and we stand behind the quality and performance of the Eyemax NVR. With its advanced features, high-resolution recording, and robustness, this NVR is a powerful tool that can enhance the security of your premises and provide you with peace of mind. Trust in Collsam Security to provide you with superior security solutions, and choose the Eyemax NVST-TX208-32 for all your surveillance needs.

Datasheet

Download

Eyemax NVST-TX208-32 NVR. High Resolution 32 Channel NVR with PoE Input and SOC Technology Perfect for home, commerce, and government security needs datasheet.

Brochure

Download

Eyemax NVST-TX208-32 NVR. High Resolution 32 Channel NVR with PoE Input and SOC Technology Perfect for home, commerce, and government security needs brochure.

SYSTEM
CompressionStandard H.264 / MPEG4
CPUCortex A9
OSEmbedded Linux
VIDEO
OutputVGA × 1:1080P HDMI × 1:1080P
IP INPUT
Resolution3Megapixel, 1080P, 960Pand 720P
Frame Rate3Megapixel, 1080P, 960Pand 720P @30 fps
AUDIO
Input32 channel IPC input
OutputRCA × 1
2-way audioRCA × 1
RECORD
Resolution3Megapixel : 2048 × 1536, 1080P : 1920 × 1080 960P : 1280 × 960, 720P : 1280 × 720 D1 : 704 × 576
Frame Rate800 fps (PAL) 960 fps (NTSC)
Bit Rate256Kbps ~ 12Mbps
EncodeVBR / CBR
Quality6 Level
ModeManual, Timer, Motion, Sensor
File ManagerLock, unlock, reserving time
PLAYBACK
Playback16 channel
SearchTime/calendar search, event (motion, external alarm)
Smart SearchApply different colors to display whether a channel in a period of time recording or not
FunctionPlay, Pause, FF, FB, Digital zoom
ALARM
ModeSensor, Motion, Video Loss
Input4 channel local input, support IPC alarm input
Output1 channel
TriggeringRecord, alarm out, e-mail, etc
NETWORK
Common InterfaceGMAC × 1
PoE InterfaceRJ45 × 8
ProtocolTCP / IP, UDP, DHCP, DNS, PPoE, DDNS, E-mail
Others18 users online, dual stream
CELLPHONE
OSiPhone, Android
FunctionMultiscreen surveillance, record, snapshot, PTZ control, save the device list
PORT
HDDSATA × 2
RS485RS 485 × 1, support PTZ and keyboard
USBUSB 3.0 × 1, USB 2.0 × 1, one for mouse, another for USB backup device
Remote ControllerYes
OTHERS
Power SupplyATX
Dimensions (W × D × H)16.93 inches (43 cm) × 11.81 inch (30 cm) × 2.17 inch (5.51 cm)
Work Environment14 °F (-10 °C) ~ 131 °F (55 °C), 10% ~ 90% Humidity

Additional information

Weight6 lbs
Dimensions18 × 13 × 4 in
Hard Drive

No Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 5 TB Hard Drive, 6 TB Hard Drive, 7 TB Hard Drive, 8 TB Hard Drive, 9 TB Hard Drive, 10 TB Hard Drive, 11 TB hard Drive, 12 TB Hard Drive, 13 TB Hard Drive, 14 TB Hard Drive, 15 TB Hard Drive, 16 TB Hard Drive, 18 TB Hard Drive, 20 TB Hard Drive
