Eyemax NVST-TS6128A NVR for Government and Commercial Use

Experience unparalleled security with the Eyemax NVST-TS6128A NVR. NDAA compliant, 128 channels, 8K output, RAID protection, and advanced analytics.

NVST-TS6128A

0 out of 5

( There are no reviews yet. )

Price range: $1,462.95 through $5,474.95

Eyemax NVST-TS6128A NVR. NDAA compliant, 128 channels, RAID protection, advanced analytics.

Support 128CH 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF IP input
H.265S/H.265+/H.265/H.264 coding
Intuitive and user-friendly Graphic User Interface (GUI), Windows-style operation by mouse
Multi-mode recording: manual/timed/motion/sensor/POS/AI recording
Playback: 16 CH simultaneous playback
Search: time slice, time, event, tag, smart, and target database search
Support face detection and comparison
Support multiple VCA (Video Content Analytics) events, such as region intrusion, tripwire, etc.
Support OS information overlay on live view and playback
Support RAID 0, 1, 5, 6, 10
Express and flexible backup via USB, network, and so on
Preview, record, playback, backup, and remote access are supported
DHCP, DDNS, PPPoE network protocol, etc.
Compatible with third-party IPCs, such as ONVIF, Hikvision, etc.
Remote control via Web Client or CMS: preview, playback, backup, PTZ and configuration
Multi-user online simultaneously
Authorization management, log view, and device status view
8K output, true high-resolution display
Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
Support NAT function and QR code scanning by mobile phones
Powerful mobile surveillance by smartphones with iOS and Android OS

SKU: NVST-TS6128A Categories: 128 Channel Network Video Recorders NVRs, Network Video Recorders (NVRs) Tags: Face detection, H.265S/H.265+/H.265/H.264 coding, IEEE 802.3i, IEEE802.3, NDAA Compliant;, Network IP PTZ, PoE (IEEE 802.3ab), PoE (IEEE 802.3u), PoE IEEE 802.3z, PoE IEEE802.3 AT/Bt, RAID 0/1/5/6/10, Sea, VCA AI Search

Hard Drive

Description

The Eyemax NVST-TS6128A is a top-of-the-line, enterprise-grade 128-channel network video recorder (NVR) designed for large-scale security systems. Part of the IP Power 6000 Series, this NVR is fully compliant with the National Defense Authorization Act (NDAA). This makes it a reliable and secure choice for government and commercial use. Built to handle massive bandwidth and ensure robust data redundancy, the Eyemax NVST-TS6128A is a powerful solution for high-density IP surveillance.

This NVR supports up to 128 IP cameras simultaneously, with an impressive incoming and outgoing bandwidth of 768 Mbps. It also offers support for recording and previewing up to 16 Megapixels (MP). This makes it ideal for high-resolution surveillance.

The Eyemax NVST-TS6128A is designed for flexibility, with support for H.265 / H.265+ / H.265S / H.264 legacy formats. This allows it to work with a wide range of cameras. It also features 4 HDMI ports, each supporting up to 8K resolution output. Additionally, it comes with 1 VGA port for added convenience.

For storage scaling, the Eyemax NVST-TS6128A accommodates 16 internal SATA hard drives and 2 external eSATA connections. It also comes with an out-of-the-box hardware configuration for RAID 0, 1, 5, 6, and 10. This provides added protection against drive failure. This allows you to store a large amount of footage without worrying about losing important data.

In addition to its impressive technical capabilities, the Eyemax NVST-TS6128A also offers advanced features for enhanced security. It supports face detection and comparison, which can be configured via 128-channel IPC-side analytics or up to 4 channels natively on the NVR. This NVR also offers human, vehicle, and license plate recognition (LPR) event classification. As a result, it is easier to identify and track potential threats.

The Eyemax NVST-TS6128A also features video content analytics, including region intrusion detection, tripwire boundary violations, and fisheye lens dewarping support. These smart features allow for more efficient and accurate surveillance, providing you with greater peace of mind.

Overall, the Eyemax NVST-TS6128A is a top-notch, intelligent NVR that offers high-performance and optimal security for demanding enterprise-level applications.

System
OS	Embedded Linux
Video
IP Video Input	128CH
Network Bandwidth	Incoming: 768 Mbps Outgoing: 768Mbps
Resolution	16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280 × 1024/960P/720P/960H/D1/CIF
Output	HDMI1: 7680 × 4320@60, 7680 × 4320@30, 3840 × 2160@60, 3840 × 2160@30, 1920 × 1080, 1280 × 1024, 1024 × 768 (When the resolution of HDMI1 output is 8K, HDMI2 is unavailable.) HDMI2: 3840 × 2160@60, 3840 × 2160@30, 1920 × 1080, 1280 × 1024, 1024 × 768 HDMI3: 3840 × 2160@60, 3840 × 2160@30, 1920 × 1080, 1280 × 1024, 1024 × 768 HDMI4: 1920 × 1080, 1280 × 1024, 1024 × 768 VGA × 1: 1920 × 1080, 1280 × 1024, 1024 × 768 (VGA and HDMI1 output the same video source)
Multi-screen Display	Main output: 1/4/6/8/9/13/16/25/32/36/64 AUX output 1: 1/4/6/8/9/13/16/25/32/36 AUX output 2: 1/4/6/8/9/13/16 Aux output 3: 1/4/6/8/9/13/16 Max. 132 (64+36+16+16)
Compression	H.264/H.265/H.265+/H.265S
Audio
Network input	128CH
Local Input	RCA×1 (for two-way talk)
Local Output	RCA×1
HDMI Audio Output	Support
Compression	G.711(U/A)
Record
Resolution	16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280 × 1024/960P/720P/960H/D1/CIF
Frame Rate	<imgheight=”11″ src=”file:///Macintosh HD/Users/media/Library/Application Support/Adobe/Dreamweaver 2021/en_US/OfficeImageTemp/clip_image001.png”>N:30fps; P:25fps</imgheight=”11″>
Playback
Simultaneous Playback	16CH
Search	Time slice/time/event/tag/smart search
Function	Play, pause, FF, rewind, digital zoom, previous frame, next frame, etc.
Decoding Capability
Live View	1CH 16MP@30 / 4 CH 12MP (only available for main output)
Playback	1CH 16MP@30 / 4CH 8MP (only available for main output)
Alarm
Mode	Manual, sensor, motion, exception, smart events, etc.
Input	24CH
Output	8CH
Triggering	Record, snapshot, preset, e-mail, etc.
Face
Face Detection Performance (AI by IPC)	128CH
Face Detection Performance (AI by Device)	4CH
Face Match Performance	16CH
Comparison Capability	36 pictures/second
Face Picture Database	32 libraries 10000 face pictures
Face Picture Search	Search by picture is supported
Database Management	Add, modify, delete, and search face pictures
Face Picture Adding	Add face pictures through APP, WEB, and external import
Face Picture Comparison	Supports successful face recognition alarm and stranger match alarm
Track	Track display on a map
Statistical Graph of Information	Bar graph
Statistical Mode of Information	Statistics by day, week, month, and quarter, as well as customized time
Video Structure Analysis
Human/Vehicle Classification (AI by IPC)	128CH
Human/Vehicle Classification (AI by Device)	8CH
Human/Vehicle Attribute Analysis	Yes
Other Functions
Fisheye	Supports fisheye dewarping via NVR/Web Client/mobile APP
Plate Recognition (AI by IPC)	Yes
Network
Protocol	TCP/IP, HTTP, HTTPS, 802.1x, FTP, DHCP, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IPv6, UDP, WebSocket, PPPoE, SNMP, IGMP
Interface	RJ45 10/100/1000Mbps × 2
Client Connection	Max. 128 users access
Mobile Device
OS	iOS, Andriod
Storage
HDD Interface	SATA×16 max 10TB per HDD
RAID Type	RAID 0, 1, 5, 6, 10
E-SATA Interface	2
Port
USB	USB 3.0 × 1, USB 2.0 × 3(Front:2)
RS485	Yes (full-duplex), connect to PTZ or keyboard
RS232	Yes
Reset	Yes
Remote Controller	No
Others
Power	ATX-275W
Consumption	≤50W (without HDD)
Dimensions	CE, FCC
Certificate
Environmental Protection	Directive EU RoHS, WEEE (2012/19/EU), Directive 94/62/EC, and REACH (EC1907/2006)
Working Environment	14°F (-10°C) ~ 122°F (50°C); Humidity: 10% ~ 90%

Additional information

Weight	35 lbs
Dimensions	21 × 21 × 7 in
Hard Drive	No Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive, 10 TB Hard Drive, 12 TB Hard Drive, 24 TB Hard Drive, 36 TB Hard Drive, 48 TB Hard Drive, 56 TB Hard Drive, 64 TB Hard Drive, 76 TB Hard Drive, 88 TB Hard Drive
