CB-CP-GN05-95S
$79.95
CB-CP-GN05-95S RG59-U Siamese Coax and 18-2 Power Combo Cable, Split Type, 500 ft (152.4 m) on a Plastic Reel
- RG59-U Coax, Bare Copper, 20 AWG
- 18 AWG-2 Conductors, Copper Clad Aluminum (CCA)
- Copper Clad Aluminum (CCA) Braid 95% • PVC Jacket
- Description
- Product Documents
- Specifications
- Additional information
- Collsam Brands
Description
The CB-CP-GN05-95J is a reliable 500-foot RG59/U Siamese shielded coaxial and power combo cable. It is designed for CCTV analog camera installations. By combining video and power into a single cable assembly, it helps streamline runs, reduce clutter, and simplify the overall wiring process.
Built as an RG59/U Siamese coaxial + 18/2 power combo, this cable is well suited for security camera systems that require a clean, efficient installation. It allows installers to transmit the video signal and deliver power through one jacket. As a result, it becomes easier to manage long cable routes in residential, commercial, and industrial environments.
The coaxial portion features 20 AWG bare copper construction with a 95% Copper Clad Aluminum (CCA) braid for dependable signal performance. This shielded design helps support stable video transmission while reducing interference. Therefore, it makes the cable a practical choice for analog CCTV applications.
The power section includes 18 AWG wire with 2 conductors, providing the needed power delivery alongside the video line. Encased in a durable outer PVC jacket, the cable offers added protection and flexibility during installation. Thus, it helps the cable hold up well in typical security wiring setups.
Packaged as a convenient reel-in-a-box, the 500-foot length gives installers plenty of cable for larger projects or multiple camera runs. The CB-CP-GN05-95J is an efficient, all-in-one solution for anyone looking to simplify CCTV camera wiring. Importantly, it does this without sacrificing performance or installation convenience.
| CONDUCTOR | |
|---|---|
| Material | Bare copper |
| Size | 20 AWG |
| Construction | Solid |
| INSULATION | |
| Material | Foamed PE |
| O.D. | .146” |
| Color cord | White |
| SHIELDS | |
| Braid | 95% coverage copper clad aluminum |
| JACKET | |
| Material | PVC |
| O.D. | .236” nom |
| Color | Black or White |
Two 18 AWG Conductors
| CONDUCTOR | |
|---|---|
| Material | copper-clad aluminum |
| Size | 18 AWG |
| Stranding | 7/.015 |
| INSULATION | |
| Material | HD-PE |
| O.D. | .069” |
| Color cord | black, Red |
| JACKET | |
| Material | PVC is extruded over coax and paired with a web attached |
| O.D. | .196 × .69 |
| OUTER JACKET | |
| Material | PVC |
| O.D. | .236 × .472 |
| Color | Black or White |
| Markings | CCTV COMBO RG59/U+18/2 CL2 BLACK (or WHT) 95% COPPER E348365 Lot#XXXXXXXXX 002FT (004FT….006FT).. 500FT |
| ELECTRICAL PROPERTIES | |
| Temperature | -4°F (-20°C) to 167°F(75°C) |
| Capacitance | 15.8 pF/Ft. nom |
| Impedance | 75 Ohms nom. |
| Velocity of Propagation | 82% nom. |
| Dielectric Strength | 500 VRMS min. |
| Max Attenuation | 55 MHz -> 1.84 Db/100 ft (30.48 m) 240MHz -> 3.57Db/100 ft (30.48 m) 400MHz -> 4.66Db/100 ft (30.48 m) 600MHz -> 5.75 Db/100 ft (30.48 m) 800MHz 6.71 Db/100 ft (30.48 m) |
| PUT=UPS | 500ft (152.4 m) / Reelex CTN |
Additional information
| Weight | 15 lbs |
|---|---|
| Dimensions | 18 × 9 × 18 in |
| Color | Black, White |
