SMT-1030PV
Original price was: $1,000.00.$620.95Current price is: $620.95.
Hanwha Vision SMT-1030PV10 10″ IP public view monitor,1080p HDMI, VGA, Ethernet, face detection display for visual deterrent, 2MP IP camera built-in, 4.6mm
- 10.1” LED 1080p resolution PVM monitor and camera
- Latency-free viewing
- Inconspicuous integrated camera
- Face Detection display for visual deterrent (Colored bounding box around detected face)
- Wide Dynamic Range (150dB)
- Advanced video analytics, motion detection
- Customizable text overlay with pre-configured “Recording in progress” OSD
- Internally Powered Camera
- Micro SD/SDHC/SDXC memory slot (256GB)
- H.265, H.264, MJPEG triple codec, Multiple streaming
- IP video and network manageable
- PoE+ / 12v DC powered
- Description
- Attachment
- Speciifications
Description
Introducing the Hanwha Vision SMT-1030PV 10″ IP public view monitor, the ultimate security solution for your business or organization. This state-of-the-art monitor boasts a 1080p resolution (1920×1080) for crystal-clear display quality. With HDMI and VGA ports, it can easily connect to various devices. This makes it a versatile and convenient option for any setting.
Designed for maximum security, the Hanwha Vision SMT-1030PV features an Ethernet port for seamless integration into your network. This allows you to remotely monitor your premises.
One of the standout features of this IP public view monitor is its face detection display, which serves as a visual deterrent for potential intruders. This feature utilizes the 2MP IP camera built-in to the monitor to detect and display faces. It alerts anyone in the vicinity that they are under surveillance. This not only helps prevent crime, but also provides valuable evidence in case of any incidents.
Equipped with a 4.6 mm fixed lens, with a 73.8-degree horizontal viewing angle, this monitor offers a wide coverage range. Thus, it reduces the need for multiple cameras. The 150dB WDR (Wide Dynamic Range) technology ensures clear images even in difficult lighting conditions, providing accurate and detailed surveillance. The H.265/H.264/MJPEG video compression options allow for efficient storage and transmission of footage. This saves you time and money eventually.
The Hanwha Vision SMT-1030PV offers more than just security, with its slide show and live video capabilities. This feature allows you to display advertisements, promotions, or other important information on the screen. Thus, it makes it a valuable tool for marketing and communication purposes. Powered by either a 12VDC power supply or PoE+ (Power over Ethernet), this monitor offers a hassle-free installation. It can be powered through a single cable.
| DISPLAY | |
| Screen Size | 10.1” LED backlight |
| Resolution (HxV) | 1024 × 600 |
| Brightness | 500cd/m² |
| Contrast Ratio | 500:1 |
| Aspect Ratio | 16:9 |
| Viewing Angle (H/V) | 140° / 120° |
| Display Color | 262,000 |
| Response Time | 20ms |
| Video System | NTSC / PAL |
| Panel Life | 50,000 hours |
| Filter Type | 3D Comb Filter / Noise Reduction / Deinterlacer |
| Key features | Customizable text overlay and blinking “Recording in progress”, Slide show |
| INTERFACE | |
| Display connector | NA |
| Network Connector | 1 RJ-45 10/100BASE-T |
| Reset (For Camera) | Yes |
| Language | English, Spanish, French, German, Italian |
| Memory Slot | Micro SD/SDHC/SDXC (Maximum 256GB) |
| Alarm | In 1/ Out 1 |
| ENVIRONMENTAL | |
| Operating temperature/ humidity | 32 °F (0 °C)~ 122°F (50 °C) Up to 104 °F (40 °C) @ ≤90% RH, up to 50°C @ ≤50% RH. |
| Storage temperature/ humidity | -4 °F (-20 °C) ~ 140 °F (60 °C) Up to 104 °F (40 °C) @ ≤90% RH, up to 140 °F (60 °C) @ ≤35% RH |
| Certification | UL, CE, FCC |
| ELECTRICAL | |
| Input Voltage | IEEE802.3at PoE+, DC 12V (110AC – 12V DC Adapter included) |
| Power Consumption | PoE+ 48V 0.28A 13.44W, DC12V 1A |
| MECHANICAL | |
| Color / Material | Black / Galvanized Steel |
| Product dimensions(WHD) / weight | 9.69 inches (24.61 cm) x 7.1 inches (18.03 cm) x 2.55 inches (6.48 cm) / 4.41lbs Shipping 13.31 inches (33.81 cm) x 10.87 inches (27.61 cm) x 6.02 inches 6.61lbs |
| Bezel Size | Top/Side: 11.7 mm Bottom: 43.4mm |
| Vesa Mounts Interface | VESA 75mm x 75mm (M4 x 10mm) |
| CAMERA | |
| Imaging Device | 1/2.8” 2 Megapixel CMOS |
| Effective Pixels | 1,945(H) x 1,097(V) 2.13Megapixel pixels |
| Minimum Illumination | Color : 0.06 Lux (1/30sec, F2.5) |
| Focal Length (Zoom Ratio) | 4.6mm |
| Wide Dynamic Range | 150dB |
Video Compression Format | H.265 / H.264 / MJPEG |
| Application Programming Interface | ONVIF Profile S/G, SUNAPI (HTTP API) |
