UID-0032V
- 2.8 ~ 12 mm Fixed Lens
- Indoor Type
- True Day & Night (ICR)
- 0 Lux at IR On (35pcs IR, 100ft (30.48 m) IR Distance)
- Support UTC Function
- DC 12V
- Description
- Product Documents
- Additional information
- Collsam Brands
- Reviews (0)
Description
UID-0032V EX-SDI – HD-SDI 1080P(2MP) IR Indoor Dome Camera Varifocal Lens and 35 IR LED
UID-0032V EX-SDI has replaced HD-SDI as the new digital interface for coax-connected cameras. EX-SDI is anticipated to offer HD-1080P over coax. Bullet cameras offer easy maneuverability, and are more ideal for viewing parallel to a wall. Bullet cameras usually have longer infrared distances. UID-0032V Dome cameras are more idea for viewing away from a wall, and frequently have better tamper-proofing options.
UID-0032V EX-SDI utilize low frequency signal combine with the new VLC (Visually Lossless CODEC) technology, able to
push up 99% identical image quality at more than twice the transmission distance.
UID-0032V EX-SDI is built in mind of adopting 4K resolution to security. Thanks to the EX-SDI VLC feature, because of
that it is possible to transmit 4K in real time FPS over coaxial cable.
UID-0032V EX-SDI Magic series will work with any HD-SDI cameras. Just like the Magic series once were compatible
with their predecessors’ technologies.
UTP cable is another option to transmit EX-SDI video signal in order to reduce cable cost. Specialized video
balun for EX-SDI is required. (sold separately)
- Indoor, Day & Night Vision 1080p FULL HD Flawless Video Dome Camera—EX-SDI HD-SDI, 2 large Cob IR LED for up to 30ft (9.14 m) IR.
- Anti-IR Reflection Series (The Shield) : prevents washed out video caused by IR reflection from obstacles (water or oil) on cover, indoor dome camera, —
- 1/2.9” Sony CMOS, 2pcs COB IR : See many details in a great distance —
- 2.8 ~ 12 mm Mega Pixel Lens, True Day & Night(ICR), DNR, D-WDR, EX-SDI / HD-SDI selectable, Balun compatible, size 4.7” x 3.6–, made in Korea
- Package: Does not include power adapter. DC 12V 1500mA minimum or higher Amps require working. RG6 cable recommended for video installation.
Additional information
| Weight | 1.06 lbs |
|---|---|
| Dimensions | 6 × 5 × 5 in |
| Color | Black, White |
Brand
Eyemax
Professional Video Surveillance Solutions
Eyemax offers surveillance technology designed for homes, businesses, offices, retail locations, schools, warehouses, and other properties. Available equipment supports both network-based and coaxial security installations.HD Coaxial Camera Solutions
HD-over-coax technology provides high-resolution surveillance while allowing compatible existing coaxial cabling to remain in service. This can provide a practical upgrade path for installations that already use traditional CCTV infrastructure.Available camera styles can support indoor and outdoor monitoring requirements, including dome, bullet, turret, and other common surveillance configurations.Network Camera Solutions
Network-based cameras provide flexible deployment options for modern surveillance environments. Depending on the equipment selected, network technology can support high-resolution imaging, remote monitoring, and integration with compatible recording systems.This approach is suitable for new installations as well as projects requiring system expansion and centralized management.NVR Recording Solutions
Network recording equipment provides centralized storage and management for compatible IP surveillance systems. Recorder selection should consider camera count, resolution, storage capacity, network requirements, and desired recording retention.Remote viewing capabilities can also provide authorized users with access to compatible surveillance systems from supported devices.DVR Recording Solutions
Coaxial recording equipment provides reliable video recording for compatible HD analog camera systems. These recorders can support upgrades to existing surveillance installations while preserving compatible cabling and infrastructure.Hybrid configurations may also provide additional flexibility when combining different surveillance technologies.Complete Security System Solutions
A complete surveillance installation can include cameras, recorders, storage, power equipment, cables, mounts, connectors, monitors, and other accessories.Collsam Security offers Eyemax products and supporting security equipment for new surveillance installations, upgrades, expansions, and replacement projects.Only logged in customers who have purchased this product may leave a review.
