TVST-PVT-08N
Eyemax PVT N5 Series TVST-PVT-08N 8 CH 3MP H.265 Penta-brid TVI, AHD, CVI, IP, 960H DVR 2 x SATA
- Full GUI with alpha blending
- Individual setting of resolution, frame rates and picture quality
- Instant Replay
- Digital Zoom
- Mouse Control
- Weekly scheduler with holiday by 10 minutes setting
- Covert, Disable and Private function of cameras
- Motion Detection with 576 area setting
- Relay alarm output
- PTZ control by RS-485
- Daylight Saving Time and Network Time Setting
- Multi-User Authority up to 8 Users
- Deinterlacer upon live and playback
- 22 languages with full graphic
- Individual Network port setting
- Auto Deletion
- Import and Export the configuration
- Interactive setup via network
- POS Interface
- Mirroring
- Dual CODEC engine for independent video transmission
- Description
- Product Documents
- Specifications
- Additional information
- Collsam Brands
- Reviews (0)
Description
The Eyemax TVST-PVT-08N 8 Channel 3 Megapixel Quadbrid DVR System is the ultimate security solution for any security installation. Security installers get everything they need to make a comprehensive and effective security system with this powerful DVR system.
This DVR can show 960H cameras, which is great for replacing an outdated system. Upgrading to HD over coaxial cable technologies is a great choice for those looking to upgrade from analog to HD.
The Eyemax TVST-PVT-08N 8 Channel 3 Megapixel Quadbrid DVR System can display 960H cameras. It’s compatible with older analog cameras, so people can swap out their current system without having to change everything. This saves you time and money and makes the installation process more comfortable.
The Eyemax TVST-PVT-08N 8 Channel 3 Megapixel Quadbrid DVR System can also work over coaxial cable. This means that customers can upgrade to higher resolution cameras without having to rewire their entire system. This feature is especially useful for analog-to-HD upgrades, as it allows for a smoother and more cost-effective transition.
The Eyemax TVST-PVT-08N has 8 channels and can be used for both small and big security systems. This DVR is perfect for customers who only need mega pixel resolutions in select areas. This allows for a customized and tailored security system that meets the specific needs of each customer.
The Eyemax TVST-PVT-08N is a powerful security system with 8 channels and 3 megapixels. Security installers can use it to make good security systems. It can display both analog and HD cameras, support HD over coaxial cable technologies, and customize IP capabilities. Trust in Eyemax for top-of-the-line security solutions that provide peace of mind for both installers and customers alike.
| Video | ||
| Camera Input | 8 BNC | |
| Individual HD/Analog Selectable | All Hybrid | |
| Output | 1 HDMI (Main Display) / 1 VGA (Main Display) | |
| Audio | ||
| Audio Input | 4 RCA | |
| Audio Output | 1 RCA | |
| Sensor In | 4 (NC, NO Selectable) | |
| Alarm Out | 1 Relay | |
| Operating System | Embedded Linux OS | |
| Display | ||
| Speed | Real-Time | |
| Resolution (Pixel) | 1280×1024, 1280×720, 1920X1080 | |
| Split Screen | 1, 4, 6, 8, 9 | |
| Main Recording | ||
| CODEC | H.264 | |
| Resolution (Pixel) | 1080p (1080p25,30) 720p (720p25,30) 960H, D1 (Composite, 960H) | |
| Picture Quality | 4 steps (Super, High, Medium, Low) | |
| Speed | NTSC Area: 240fps@720p/120fps@1080p PAL Area: 200fps@720p/100fps@1080p | |
| Dual Recording | ||
| CODEC | H.264 | |
| Resolution (Pixel) | N/A | |
| Playback | ||
| Display | 1, 4, 6, 8, 9 | |
| Search Mode | Calendar, Event, POS, Panorama, Thumbnail | |
| Speed | NTSC Area: 60fps@1080p PAL Area: 50fps@1080p | |
| Fast/Slow Speed | Normal, REW & FF [Recorded speed x2, x4, x8, x16,×32,×64,×1/2,×1/4], Frame to frame, Pause | |
| Network | ||
| Network Interface | Megabit Ethernet | |
| Low Resolution (Pixel) | 480×256 (1080p25,30) 480×256 (720p25,30) CIF (Composite, 960H) | |
| Speed | NTSC Area: 40fps@720p PAL Area: 40fps@720p | |
| Protocol | TCP/IP, HTTP, DHCP | |
| Application | Windows 7 / 8 (PC Client System & I.E.,)/ MAC | |
| Web Browser | Internet Explorer, Safari, Chrome, Firefox | |
| Smartphone App | Android, iPhone for Live & Search | |
| Backup | ||
| Interface | USB 2.0 × 2 | |
| Backup Device | External HDD, CD & DVD-RW, Network, Thumb Drive | |
| The Number of HDD | 1 × SATA | |
| Others | ||
| Power Consumption | 24W | |
| Operating Temperature | 41 °F (5 °C)~104 °F (40 °C) | |
| Relative Humidity | Maximum 80% non-condensing | |
Additional information
| Weight | 7 lbs |
|---|---|
| Dimensions | 12 × 9 × 3 in |
