-20%

EC-T4F28M

Uniview EC-T4F28M High-quality image with 4Megapixel Fixed Eyeball Network Camera. 1/3”CMOS sensor; 4MP (2560×1440)@25/20fps; 3MP (2304×1296)@30/25fps; 2MP (1920×1080)@30/25fps; 720P 1280×720)@30/25fps

EC-T4F28M

Original price was: $259.00.Current price is: $207.20.

In stock
0 out of 5

Original price was: $259.00.Current price is: $207.20.

Uniview EC-T4F28M High-Quality Image 4Megapixel Fixed Eyeball Network Camera

  • 4MP (2560×1440)@25/20fps, 3MP (2304×1296)@30/25fps, 2MP (1920×1080)@30/25fps, 720P (1280×720)@30/25fps
  • Ultra 265, H.265, H.264, MJPEG Compression
  • Smart IR, up to 30m (98.43 ft) IR distance
  • Supports 128G Micro SD card
  • Support PoE power supply
  • 3-Axis
NDAA-compliant security products at Collsam SecurityUniview security cameras and NVR systems are available at Collsam Security

Description

The Uniview EC-T4F28M is the perfect choice for those wanting high-quality images with unsurpassed performance. This 4 megapixel fixed eyeball network camera has a 1/3”CMOS sensor and can capture images at 25/20fps. It can also record videos at up to Ultra 265, H.265, H.264, and MJPEG compression.

This camera’s features don’t stop there, it also supports PoE power supply along with a 128G Micro SD card and 3-Axis for positioning. With its Smart IR feature, the camera can also reach up to 30m (98.43 ft) of IR distance. This means that you can capture stunning images in low light conditions.

The Uniview EC-T4F28M is a great choice for anyone looking for an easy to use, yet powerful solution. It is specifically designed for surveillance and security applications, and it offers exceptional image quality. With its motion detection, you can be sure that any unwanted movement will be captured and sent to your device immediately.

The camera is also designed to be durable and is made from high-quality materials. Its compact design means that it can be easily mounted in any location. It also comes with a flexible lens, so you can customize the angle of view to get the most out of the camera’s capabilities.

Overall, the Uniview EC-T4F28M is a great choice for anyone looking for a powerful and high-quality fixed eyeball network camera. With its advanced features and capabilities, it is certain to provide you with superior image quality and reliable performance. Its affordability and ease of use makes it ideal for surveillance and security applications.

Datasheet

Download

Uniview EC-T4F28M High-quality image with 4Megapixel Fixed Eyeball Network Camera. 1/3”CMOS sensor; 4MP (2560×1440)@25/20fps; 3MP (2304×1296)@30/25fps; 2MP (1920×1080)@30/25fps; 720P 1280×720)@30/25fps Datasheet

User's Manual

Download

Uniview EC-T4F28M High-quality image with 4Megapixel Fixed Eyeball Network Camera. 1/3”CMOS sensor; 4MP (2560×1440)@25/20fps; 3MP (2304×1296)@30/25fps; 2MP (1920×1080)@30/25fps; 720P 1280×720)@30/25fps User's Manual

Camera
Sensor1/3”, 4.0 megapixel, progressive CMOS Scan
Min. IlluminationColor: 0.01Lux (F2.0, AGC ON) 0Lux with IR
Day/NightIR-cut filter with auto-switch (ICR)
ShutterAuto/Manual, 1 ~ 1/100000s
Adjustment anglePan: 0° ~ 360°, Tilt: 0° ~ 75°, Rotate: 0° ~ 360°
S/N>56dB
WDRDWDR
Lens
Lens Type2.8mm @2.0, Fixed-focal
Lens MountM12
Angle of View (H)97.0°
Angle of View (V)52.2°
Angle of View (O)107.5°
DORI
DORI DistanceLens (mm)DetectObserveRecognizeIdentify
2.8196.85 ft (60 m)82.68 ft (25.2 m)41.34 ft (12.6 m)20.67 ft (6.3 m)
Illuminator
IR RangeUp to 98ft (29.87 m) IR range
Wavelength850nm
IR On/Off ControlAuto/Manual
Video
Video CompressionUltra 265, H.265, H.264, MJPEG
H.264 code profileBaseline profile, Main profile, High profile
Frame RateMain Stream: 4MP (2560×1440), Max 25fps; 3MP (2304×1296), Max 30fps; 1080P (1920×1080), Max 30fps; 720P (1280×720), Max 30fps
Sub Stream:D1 (720×576), Max 30fps; 640×360,Max 30fps; 2CIF (704×288), Max 30fps; CIF (352×288), Max 30fps;
Video Bit Rate128 Kbps~6144 kbps
U-codeSupported
OSDUp to 4 OSDs
Privacy MaskUp to 4 areas
ROIUp to 8 areas
Motion DetectionUp to 4 areas
White BalanceAuto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Image SettingImage rotation, brightness, saturation, contrast, sharpness, gain adjustable by web browser
Digital noise reduction2D/3D DNR
Smart IRSupport
FlipNormal/Vertical/Horizontal/180°
DewarpingN/A
HLCSupported
BLCSupported
DefogDigital Defog
Events
Behavior DetectionCross line, intrusion (based on human body detection)
Motion detection, tampering alarm
General FunctionWatermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication
Storage
Edge StorageMicro SD, up to 128GB
Network StorageANR, NAS(NFS)
Network
ProtocolsIPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS, SSL/TLS, SNMP
Compatible IntegrationONVIF (Profile S, Profile G, Profile T), API, SDK
User/HostUp to 32 users. 2 user levels: administrator and common user
SecurityPassword protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
ClientEZStation
EZView
EZLive
Web BrowserPlug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chrome 57.0+, Firefox 58.0+, Edge 16+
Interface
Network1 * RJ45 10M/100M Base-TX Ethernet
Certification
EMCFCC: FCC Part 15
SafetyCE: EN 60950-1
UL: UL60950-1
IEC 60950-1
General
PowerDC 12V±25%, PoE (IEEE 802.3af)
Power consumption: Max 4.0W
Power InterfaceØ 5.5mm coaxial power plug
Dimensions (Ø x H)Φ 4.6 inch (11.68 cm) x 3.8 inch (9.65 cm)
Weight0.30kg (0.66lb)
MaterialMetal + Plastic
Working Environment-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Storage Environment-22 °F (-30 °C) ~ 140 °F (60 °C), Humidity: ≤95% RH (non-condensing)
Surge Protection4KV
Reset ButtonN/A
Ingress ProtectionIP67 Ingres protection:

Additional information

Weight3 lbs
Dimensions8 × 6 × 8 in
