USQ-202-B36
Eyemax USQ-202-B36 1080P 2 Megapixel EX-SDI HD-SDI Mini Hidden Camera Square Camera with 3.6 mm Pinhole Fixed Lens, DC 12V
- 1/2.9” SONY CMOS sensor.
- Extended Serial Digital Interface
- 1 LUX @F1.2, 0.1 LUX Black and white
- DNR (Digital Noise Reduction)
- Day and Night (ICR Option)
- Easy Installation
SKU: USQ-202-B36
Categories: 2 Megapixel HD Coaxial Cameras, Covert Cameras and DVRs, Covert Hidden Camera, HD Coaxial Cameras, Spy and Surveillance Equipment
Tags: 12V DC power, 2 Megapixel Lens , 3.6 mm Pinhole Fixed Lens, Covert Hidden Camera, EX-SDI, Fixed Focal, Mini Hidden Camera, USQ 202-B36- Description
- Attachment
- Speciifications
- Additional information
Description
Introducing the Eyemax USQ-202-B36, a top-of-the-line 1080P EX-SDI or HD-SDI hidden square case camera. This high-definition camera boasts a 1080P resolution and a 3.6 mm fixed lens, providing crystal-clear images that capture every detail. With its 1/2.9-inch SONY CMOS sensor, the Eyemax USQ-202-B36 is a great tool for security and surveillance applications.
Even when there isn’t much light, the USQ-202-B36 gives you a great picture. It has 0.1 LUX for black and white and 1 LUX @F1.2 for color. With its DC 12V power source, this camera is not only reliable but also energy-efficient, making it suitable for long-term continuous use. Whether used in homes, offices, or commercial spaces, this camera offers top-notch performance, ensuring that no detail goes unnoticed.
One of the standout features of the Eyemax USQ-202-B36 is its DNR (Digital Noise Reduction) technology. This revolutionary technology eliminates noise and interference from the video feed, providing clear and crisp images even in challenging environments. Consequently, it is an optimal option for outdoor surveillance, where disturbances such as wind and rain are probable.
Another feature that sets the USQ-202-B36 apart is its Day and Night (ICR Option). This allows the camera to switch seamlessly between color and black and white modes as lighting conditions change. Whether it’s day or night, the Eyemax USQ-202-B36 guarantees exceptional image quality, ensuring that you don’t miss any important details.
This feature is particularly useful for 24/7 surveillance, making it an ideal choice for both home and commercial use.
In conclusion, the Eyemax USQ-202-B36 is a top-of-the-line hidden square case camera that delivers exceptional performance and superior image quality. Thanks to its 1080P resolution, 3.6 mm fixed lens, and sophisticated features like Day and Night functionality and DNR, the camera is indispensable for all your security and surveillance needs. Whether it’s for personal or professional use, the USQ-202-B36 is the ultimate choice for reliable and efficient surveillance.
| Resolution | 1080P 2 Megapixel |
| Sensor | 1/2.9” SONY CMOS (IMX-222 / IM × 322) |
| Total Pixels | 2000(H) × 1241(V) = 2,482,000 |
| Effective Pixels | 1944(H) × 1092(V) = 2,122,648 |
| Scanning System | PROGRESSIVE |
| S/N (Y signal) | More than 52 dB (AGC Off) |
| Video Output | SMPTE292M (HD-SDI) / (CVBS: 1.0Vp-p (75ohm) : Option) |
| Min.Illumination | 1 LUX @F1.2 / 0.1 LUX Black and White |
| White Balance | AUTO |
| Electronic shutter speed | AUTO |
| DNR | ON |
| Day & Night | AUTO (Day <–> Night TIME Change) |
| Temperature/Humidity | Operating at 14 °F (-10 °C) ~ 158 °F (70 °C) / 30% ~ 80% RH) Storage at 14 °F (-10 °C) ~ 104 °F (40 °C) / 20% ~ 90% RH) |
| Power | 12V DC |
| signal Transmission | The distant difference occurred according to cable option and other circumstances. (based on 5C-HFBT: HD-SDI 656.18 ft (200 m) / EX-SDI 1312.34 ft (400 m)) |
Additional information
| Weight | 1 lbs |
|---|---|
| Dimensions | 3 × 3 × 3 in |
