SPD-151
Hanwha Vision SPD-151 48 Channel Network Video Decoder
- Video stream decoding up to 12MP
- 4K UHD HDMI output, 1080p VGA output, and 4CIF CVBS output
- Management via local user interface
- Clone and expand mode support (HDMI, VGA)
- Various view modes including hallway view
- Up to 20 layouts and sequence
- Wizard installation functionality enables configuration export and import
- PoE or 12 VDC power
- Updates via USB
- NTP and manual time setting
![]() |
Replacement Product |
- Description
- Attachment
- Specifications
- Additional information
Description
The Hanwha SPD-151 is a powerful and versatile network video decoder that is perfect for any surveillance or security system. This decoder can decode video from up to 48 cameras, so users can see everything around them. Video can be sent from a single camera using the HDMI and VGA ports. This decoder is also capable of decoding video at up to 12MP resolution, ensuring clear and detailed footage.
The Hanwha SPD-151 can show 4K UHD video through its HDMI port. This means that users can enjoy high-resolution video playback for a more immersive viewing experience. In addition, the SPD-151 supports various HDMI view modes, including ½×2, 3×3, 4×4, 5×5, and 6×6, allowing for customizable and multi-camera display options. Users can also utilize the VGA View Merge 1, 2×2, 3×3, 4×4, and BNC 1 Tile merge support for even more versatile layouts.
This computer can handle different video formats, like H.265, H.264, and MJPEG. This helps it work with many surveillance devices. The SPD-151 also offers 12V DC and PoE (Power over Ethernet) options for convenient power supply. Users can also manage the decoder using the Web-Viewer, making it easy to control and monitor the system remotely.
When it comes to reliability and quality, you can trust Collsam Distribution for all your Hanwha Vision products. Collsam is a trustworthy supplier who only buys things from reputable companies. This makes sure that clients get good products that are better than what they expected. The Hanwha SPD-151 is a good product from Collsam. They have good customer service and support, so you can shop easily.
The Hanwha SPD-151 is a network video decoder that is great for any surveillance or security system. Support for various video codecs and customizable display options make this decoder an unparalleled choice for users. Trust Collsam Distribution for all your Hanwha Vision product needs and experience the best in surveillance technology.
NETWORK | ||
CPU | Embedded CPU | |
Operating System | Embedded Linux | |
Output | HDMI | 1ea (up-to 4K) |
VGA | 1ea (up-to 1080p) | |
CVBS | 1ch (BNC 1ea) | |
Video-out Format | 3840 X 2160@60HZ/30HZ (HDMI1), 2560 X 1440@60HZ/30HZ (HDMI1), 1920 X 1080@60HZ, 1280 X 1024@60H, 1280 X 720@60Hz | |
External | Ethernet | 1ea (10/100/1000BASE-T) |
USB | USB 2.0 2ea | |
Audio Out | 1 out | |
LED | Power, Network | |
ENVIRONMENTAL | ||
Operating Temperature | 32 °F (0 °C) ~ 104 °F (40 °C) | |
Humidity | 20% ~ 85% RH | |
ELECTRICAL | ||
Power | 12V DC, PoE (IEEE802.3af) | |
Power Consumption | Maximum 8.4W (12V DC), Maximum 8.4W (PoE) | |
MECHANICAL | ||
Color / Material | Dark Gray / Metal | |
Dimension (W × H × D) | 7.01 inches (17.81 cm) x 1.34 inch (3.4 cm) x 7.39 inch (18.77 cm) | |
Weight | Approximately 1.50 lb (0.68 kg) | |
SOFTWARE | ||
Video | Codec | H.265/H.264/MJPEG |
Max. Decoding Performance. | 16 × 2M (1080P)@30fp, 8MP@30fps | |
Max. Decoding Resolution. | Up-to 12MP | |
Max. Decoding Bandwidth. | 200Mbps | |
Division (/Monitor) | (HDMI) 1/2×2/3×3/4×4/5×5/6×6(32Ch Only) (VGA) 1/2×2/3×3/4×4 (BNC) 1 | |
Layout | Up-to 20ea/monitor, Sequence support | |
Merge | Monitor Merge | 1×2, 2×1 |
Tile Merge | Support | |
Audio | Codec | G.711/G.726/AAC |
Management | Web-Viewer, SSM | |
Time Setting | NTP / Manual | |
Export / Import | Configuration Export/Import | |
Log | Maximum 20000 (System log, Event log each) | |
Protocol | SUNAPI 2.3 or later |
Additional information
Weight | 2 lbs |
---|---|
Dimensions | 9 × 9 × 3 in |
