SPO-8315

Power up your network with the Hanwha SPO-8315, an 83W HPoE and PoE++ injector that's compatible with existing switches and follows industry standards. Shop now at Collsam.com!

SPO-8315

In stock
0 out of 5

Hanwha SPO-8315 83W HPoE or PoE++ Injector with Built-in SFP Slot

  • 83W / 1.5A HPoE injector
  • SFP port included
  • 100-240V AC 2.0A 50/60Hz Input
  • 55Vdc 1500mA Output
  • 4/5(+), 7/8(-) and 3/6(),1/2(-) Power Pins
  • 10/100/1000BASE-T RJ45 Interfaces 1000BASE-X SFP Interfaces Data Speed
  • Wall-mounted
  • IP20
  • NDAA Compliant
Hanwha Vision security cameras and video surveillance products at Collsam SecurityNDAA-compliant security products at Collsam Security
SKU: 8801089218476 Categories: , , , Tags: , , , , , ,

This product is no longer available.

Description

The Hanwha SPO-8315 is a powerful and versatile product designed to make your network more efficient and convenient. You can power your gadgets with the same cables that carry data with this 83W HPoE and PoE++ injector. With this injector, you don’t have to run separate power cables for each device, which saves time, money, and effort.

One of the most impressive features of the Hanwha SPO-8315 is its compatibility with existing Ethernet switches and networked devices. This means that you can easily integrate it into your current network without having to make any significant changes. The POE injector is a good choice for power over Ethernet.

The SPO-8315 follows the EEE802.3BT, IEEE802.3AT, and IEEE802.3AF standards, ensuring that it meets the highest standards of quality and performance. This makes it a reliable and trustworthy product, giving you peace of mind that your network is in good hands. You can connect to fiber-optic networks and expand your network’s reach and capabilities with this injector’s built-in SFP slot.

At Collsam.com, we are proud to be your source for everything Hanwha, including the SPO-8315 injector. Hanwha is known for producing top-notch tech and safety products, and the SPO-8315 is no exception. We are sure that the POE injector will help you reach your goals with our commitment to providing the latest technology.

Hanwha SPO-8315 is a good choice for people who want to use Ethernet wiring to power their devices. With its compatibility, standards compliance, and built-in SFP slot, this injector offers both convenience and performance. So why wait? Upgrade your network with the Hanwha SPO-8315 from Collsam.com today and experience the difference it can make.

Input and Output
Input100-240Vac 2.0A 50/60Hz
Output55Vdc 1500mA
Power Pins4/5(+), 7/8(-) and 3/6(+),1/2(-)
Data Speed10/100/1000BASE-T RJ45 Interfaces 1000BASE-X SFP Interfaces
Working Environment
Operating Temperature-40℃ to 65℃
Operating Humidity20% to 90%, non-condensation
Storage Temperature-40℃ to +85℃
Storage Humidity10% to 90%, non-condensation
Operating Altitudeup to 10,000 ft (3.05 km)
LED Indicator
Power indicatorGreen
Load active IndicatorGreen
SFP fiber indicatorGreen
LAN data indicatorYellow
PoE data indicatorYellow
Safety Approval
cUL/UL, KC, RCM, NOM, BSMI, CE, SAA, PSB, SII, EAC, FCC, ST, CCC, Ukraine, BIS, PSE, CM, LOA, CB, UKCA
Mechanical Characteristics
CaseMetal
ColorBlack
MountingWall-mounted
IP RatedIP20
Size8.4 inches (21.34 cm) x 5.26 inch (13.36 cm) x 1.6 inch (4.06 cm)
Weight2.43 lb (1,102.23 g)
Hanwha Techwin PTZ Network Cameras
  • XNP-6400RW
  • XNP-8300RW
  • XNP-9300RW
  • PNM-9085RQZ
  • PNM-9084RQZ
  • PNM-9085RQZ
  • PNM-9084RQZ
  • PNM-9320VQP
  • PNM-9321VQP
  • PNM-9322VQP

Additional information

Weight2.43 lbs
Dimensions8.4 × 5.3 × 1.6 in
