TVST-TR5716
Telpix TVST-TR5716 16 Channel TVI, AHD, CVI, Analog, IP Hybrid DVR System, H.265, up to 5 Megapixels, 8-Channel Audio, HDMI
- 16 Chanel TVI, AHD video input, support 5 megapixel, 4 megapixel, 3 megapixel, 1080P, 720P, WD1
- 16 Chanel CVI video inputs, support 4 megapixel, 3 megapixel, 1080P, 720P, WD1 Default support
- 8 Chanel IPC 5 Megapixel, 4 Megapixel, 3 Megapixel, 1080P, 960P, 720P
- Adopt the standard H.265 high-profile compression format to get high-quality video at a much lower bit rate.
- Intuitive and user-friendly Graphics User Interface (GUI), window-style operation by mouse
- Multimode recording: manual, timer, motion
- Playback : 16 CH simultaneous playback
- Search: time slice, time, event (manual, motion), tag search
- Express and flexible backup via USB, network and so on
- Pentaplex: preview, record, playback, backup and remote access
- DHCP, DDNS, PPPoE network protocol, IE browser, and CMS supported
- Remote control via IE or CMS preview, playback, backup, PTZ and configuration
- Dual-stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
- Multi-user online simultaneously
- Authorization management, log review and device status review
- 1080P output, true high-resolution display
- Support PTZ preset and auto-cruise, up to 255 presets and 8 cruises
- Support NAT function and QR Code scanning by mobile phone and PAD
- Powerful smartphone & pad surveillance with iOS and Android OS
- Description
- Product Documents
- Speciifications
- Additional information
- Collsam Brands
Description
The Telpix TVST-TR5716 is a state-of-the-art 16-channel hybrid 5-megapixel Lite high-definition DVR that offers the latest in security technology. This DVR can connect 16 analog cameras and 8 IP cameras at the same time. This is great for keeping your home and family safe. The Telpix TVST-TR5716 can help you protect your home, business, transportation, or government building.
One of the standout features of this DVR is its adoption of the standard H.265 high-profile compression format. This format allows for optimal compression and storage of your surveillance footage while maintaining crystal-clear image quality. The most advanced SOC technique is also utilized, ensuring real-time recording in each channel and unmatched system robustness. With the Telpix TVST-TR5716, you can rest assured that your security footage is in safe hands.
You can watch multiple things at once with this video recorder’s 16 channels of video and sound. It also has 4 channel output and two SATA hard drives that can hold up to 8TB of data each. A total storage capacity of up to 16TB makes it easy to store your surveillance footage for future reference.
At Collsam Distribution, we are proud to be the most affordable source for all your Telpix CCTV products. We aim to provide good security at a low cost so everyone can keep their things and loved ones safe.
With the Telpix TVST-TR5716, we have taken great care to ensure that you receive the best value for your money. With its advanced features and robust design, this DVR is sure to exceed your expectations.
To sum up, the Telpix TVST-TR5716 is an excellent DVR that has 16 channels and can record in high definition. It has amazing security and surveillance features. Its advanced compression technology, real-time recording, and user-friendly interface make it the perfect addition to any security system. And with Collsam Distribution, you can get all your Telpix CCTV products at an unbeatable price. Upgrade your security today with the Telpix TVST-TR5716.
| Video | Camera Input | 16 BNC |
| Individual HD/Analog | All Hybrid | |
| Available Source | TVI 720p25,30/1080p25,30/Composite/960H/Mixed | |
| Output | 1 HDMI (Main Display or Programmable HD Spot) 1 VGA (Main Display or Programmable HD Spot) 1 Composite (Programmable SPOT) | |
| Audio | Audio Input | 4 RCA |
| Output | 1 RCA | |
| Sensor In | 4 (NC, NO selectable) | |
| Alarm out | 1 Relay | |
| Operating System | Embedded Linux OS | |
| Display | Speed | Real Time |
| Resolution (Pixel) | 1280×1024, 1280×720, 1920×1080 | |
| Screen Split | 1 / 4 / 6 / 8 / 9 / 13 / 16 | |
| Recording | CODEC | H.264 / JPEG for 3G, Dual CODEC |
| Resolution (Pixel) | 1080p (1080p25,30) 720p (720p25,30) 960H, 720H (Composite, 960H) | |
| Picture Quality | 4 Steps (Super, High, Medium, Low) | |
| Speed | NTSC : 480fps@720p / 240fps@1080p PAL : 400fps@720p / 200fps@1080p | |
| Playback | Display | 1 / 4 / 8 / 9 / 13 / 16 |
| Search Mode | Calendar, Event, POS, Panorama, Thumbnail | |
| Speed | NTSC : 120fps@1080p PAL : 100fps@1080p | |
| Fast/Slow speed | Normal, REW, and FF [recorded speed ×2, ×4, ×8,×16,×32,×64,×1/2,×1/4], Frame to frame, Pause | |
| Network | Network Interface | Gigabit Ethernet |
| Speed | 100fps@720p | |
| Protocol | TCP/IP, HTTP, DHCP | |
| Application | Windows 7 / 8 (PC Client System & I.E.,)/MAC | |
| Web Browser | Internet Explorer, Safari, Firefox, Chrome | |
| Smartphone App | MR. Patrol : Android, iPhone for Live & Search | |
| Backup | Interface | USB 2.0 × 2 |
| Backup device | External HDD, CD and DVD-RW, Network, Thumb Drive | |
| The Number of HDD | 2 SATA 8TB capacity limit each | |
| Others | Power Consumption | 60W |
| Operating Temperature | 41 °F (5 °C)~104 °F (40 °C) | |
| Relative Humidity | Maximum 80% non-condensing | |
| Dimension | 13.39 inches (34.01 cm) (W)×9.84 inches (24.99 cm)(D)×2.36 inches (5.99 cm) (H) | |
Additional information
| Weight | 12 lbs |
|---|---|
| Dimensions | 8 × 18 × 3 in |
Brand
Telpix
