UIR-M2342V-B
Eyemax UIR-M2342V-B 2 Megapixel 1080p IR Bullet EX-SDI Camera 2.8-12 mm Motorized Auto-Iris Varifocal Lens, 30 m Infrared, 12v DC, IP68, CVBS.
- 1/2.9 inch SONY CMOS
- IMX-222
- IMX-322
- Extended Serial Digital Interface
- 0 Lux at IR On (IR LED 08pcs)
- Upgraded Waterproof Housing (IP 68 rating)
- DNR (Digital Noise Reduction)
- Digital WDR (Wide Dynamic Range)
- Day and Night (ICR Option)
- Easy Installation
- ICR Varifocal lens
- DC Auto IRIS Varifocal Lens
- DC Auto IRIS & TDN Varifocal Lens
- Auto Focus Motorized 2.8~12 mm Varifocal Lens
- Description
- Product Documents
- Specifications
- Additional information
- Collsam Brands
- Reviews (0)
Description
The Eyemax UIR-M2342V-B EX-SDI IR Bullet is a high-quality surveillance camera that offers state-of-the-art features for reliable and effective monitoring. This camera has a 2-megapixel resolution and a 1/2.9-inch SONY CMOS IMX-222 and IMX-322 Extended Serial Digital Interface. The 0 Lux at IR On feature makes it an excellent choice for nighttime surveillance, even in dim lighting.
The upgraded version of the Smart Mount II makes it easy to set up and tweak the perfect viewing angle. The camera’s new waterproof case is IP 68 and can handle tough outdoor conditions. This makes it a great option for both indoor and outdoor surveillance, providing reliable monitoring for any setting.
The Eyemax UIR-M2342V-B EX-SDI IR Bullet boasts advanced technology that enhances image quality and minimizes background noise. The Digital Noise Reduction (DNR) feature helps to eliminate grainy images, providing a clearer picture. In high-contrast scenes, the Digital WDR ensures that each element of the picture is adequately illuminated.
This camera can switch between color and black and white modes automatically, depending on the lighting. This allows for continuous monitoring and ensures that images are always clear and crisp. The camera has several lens options, including the ICR varifocal lens, DC Auto IRIS varifocal lens, and TDN varifocal lens. This allows users the flexibility to choose the lens that best suits their specific needs.
Only the best quality products are provided to our customers by Collsam Distribution, your reliable Eyemax Products distributor. We have a great camera called the Eyemax UIR-M2342V-B EX-SDI IR Bullet that is perfect for security. High-resolution images and durable design make this product a great choice for a camera for your home or business. Trust Collsam Distribution and Eyemax for all your surveillance needs.
| Resolution | 1080P, 720P |
| Sensor | 1/2.9 inch SONY CMOS (IMX-222 / IM × 322) |
| Total Pixels | 2000(H) × 1241(V) = 2,482,000 |
| Effective Pixels | 1944(H) × 1092(V) = 2,122,648 |
| Scanning System | PROGRESSIVE |
| S/N (Y signal) | More than 52 dB (AGC Off) |
| Video Output | SMPTE292M (HD-SDI) / (CVBS: 1.0Vp-p (75ohm) : Option) (TVI : OPTION) |
| Min. Illumination | IR PRODUCT : 0 Lux at IR On 1 Lux at F1.2 / 0.1 Lux (B/W) |
| White Balance | AUTO / AUTO EXT / PRESET / MANUAL |
| Electronic shutter speed | AUTO / MANUAL (1/30sec ~ 1/30,000sec) / Flicker |
| SENS_UP | OFF / × 2 / × 4 / × 8 / × 16 / × 32 |
| DNR | OFF / LOW / MIDDLE / HIGH |
| BACKLIGHT | OFF / WDR / BLC / HLC |
| ACE | OFF / LOW / MIDDLE / HIGH |
| Day & Night | AUTO (Day <–> Night TIME Change), COLOR, Black and White, EXTERN |
| PRIVACY / FLIP / FREEZE | OFF / ON |
| MOTION / DEFOG | OFF / SET |
| D.ZOOM | x1.0 ~ × 16.0 |
| Language | ENG, CHN, CHN(S), JPN, KOR |
| Sharpness / Brightness | ADJUSTABLE (Sharpness : 0 ~ 10 STEP / Brightness : 0 ~ 20 STEP) |
| COMM. | RS-485(PELCO-D) |
| Temperature/Humidity | Operating 14 °F (-10 °C) ~ 122 °F (50 °C) / 30% ~ 80% RH) Storage (-4 °F (-20 °C) ~ 140 °F (60 °C) / 20% ~ 90% RH) |
| Power | DC12V |
| signal Transmission | The distant difference is occurred according to cable option and other circumstances. (based on 5C-HFBT : HD-SDI (200M) / EX-SDI (400M)) |
Additional information
| Weight | 5 lbs |
|---|---|
| Dimensions | 19 × 8 × 8 in |
