TZ570 02-SSC-2833
Original price was: $1,649.00.$1,319.20Current price is: $1,319.20.
SonicWall TZ570 Network Security Appliance (02-SSC-2833) 8X 1GbE Ports, 2X 5GbE Ports
- Stateful packet inspection
- Reassembly-Free Deep
- Packet Inspection
- DDoS attack protection (UDP/ICMP/SYN flood)
- IPv4/IPv6 support
- Biometric authentication for remote access
- DNS proxy
- Full API support
- SonicWall Switch integration
- SD-WAN scalability
- SD-WAN Usability Wizard1
- SonicCoreX and SonicOS containerization
- Connections scalability (SPI, DPI, DPI SSL)
SKU: TZ570 02-SSC-2833
UPC: 758479228332
Categories: Firewall, Network Switch, Telephone and Network
Tags: Firewall, Firewall protection, NDAA Compliant;- Description
- Attachment
- Specifications
- Additional information
- Reviews (0)
Description
The SonicWall TZ570 02-SSC-2833 Appliance is a cutting-edge next-generation firewall (NGFW). It is specifically designed for mid-sized organizations and distributed enterprises with SD-Branch locations. This powerful desktop form-factor firewall offers unparalleled security and performance at a budget-friendly price point.
With 10 ports, including 5 Gigabit Ethernet interfaces, it can expand up to 256GB of storage. Thus, this appliance is capable of meeting the demands of even the most data-intensive networks.
One of the standout features of the SonicWall TZ570 02-SSC-2833 Appliance is its Real-Time Deep Memory Inspection (RTDMI) technology. This advanced security measure allows for the scanning of encrypted traffic, ensuring that no threats bypass the firewall undetected. Additionally, the appliance also boasts Capture Advanced Threat Protection (ATP), which is a cloud-based sandboxing solution. This provides an added layer of defense against emerging threats.
To further strengthen its defenses, the SonicWall TZ570 02-SSC-2833 Appliance includes Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, Application Firewall, and Content Filtering capabilities. These features work together to protect against a wide range of cyber threats, including viruses, malware, and intrusions. With these comprehensive security measures in place, organizations can have peace of mind. They can rest assured knowing that their networks are well-protected.
In addition to its top-of-the-line security features, the SonicWall TZ570 02-SSC-2833 Appliance also runs on SonicOS 7.0. This is a cutting-edge operating system that offers a modern interface and advanced security, networking, and management capabilities. This means that not only is the appliance highly secure, but it is also easy to use and manage. Thus, it is an ideal choice for businesses with limited IT resources.
The SonicWall TZ570 02-SSC-2833 Appliance also supports integrated SD-WAN, as well as TLS 1.3. Additional features include real-time visualization and high-speed VPN, which allow for streamlined and efficient network management. This improves network performance and security. Furthermore, the appliance is designed for simplified deployment with minimal IT support.
It is easy to roll out across multiple locations simultaneously. Additionally, with its scalability, the appliance can grow alongside a business. Therefore, it is a wise investment for organizations looking to expand in the future.
| Firewall General | TZ570 02-SSC-2833 | ||
| Operating system | SonicOS 7.0 | ||
| Interfaces | 8×1GbE, 2×5G SFP+, 2 USB 3.0, 1 Console | ||
| Wireless support | 2×2 802.11ac Wave 2 (TZ570W) | ||
| Power over Ethernet (PoE) support | 5 PoE or 3PoE+ (TZ570P) | ||
| Storage Expansion slot | Optional up to 256GB | ||
| Management | Network Security Manager, CLI, SSH, Web UI, GMS, REST APIs | ||
| Redundant power supply | Yes | ||
| Single Sign-On (SSO) Users | 2,500 | ||
| VLAN interfaces | 256 | ||
| Access points supported (maximum) | 32 | ||
| Firewall/VPN Performance | TZ570 SERIES | ||
| Firewall inspection throughput1 | 4 Gbps | ||
| Threat Prevention throughput2 | 2 Gbps | ||
| Application inspection throughput2 | 2.5 Gbps | ||
| IPS throughput2 | 2.5 Gbps | ||
| Anti-malware inspection throughput2 | 2 Gbps | ||
| TLS/SSL inspection and decryption throughput (DPI SSL)2 | 750 Mbps | ||
| IPSec VPN throughput3 | 1.8 Gbps | ||
| Connections per second | 16,000 | ||
| Maximum connections (SPI) | 1,250,000 | ||
| Maximum connections (DPI) | 400,000 | ||
| Maximum connections (DPI SSL) | 50,000 | ||
| VPN | TZ570 SERIES | ||
| Site-to-site VPN tunnels | 200 | ||
| IPSec VPN clients (maximum) | 10 (500) | ||
| SSL VPN licenses (maximum) | 2 (200) | ||
| Encryption/authentication | DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography | ||
| Key exchange | Diffie-Hellman Groups 1, 2, 5, 14v | ||
| Route-based VPN | RIP, OSPF, BGP | ||
| Certificate support | VeriSign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to- SonicWall VPN, SCEP | ||
| VPN features | Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN | ||
| Global VPN client platforms supported | Microsoft® Windows 10 | ||
| Net Extender | Microsoft Windows 10, Linux | ||
| Mobile Connect | Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Chrome OS, Windows 10 | ||
| Security Services | TZ570 SERIES | ||
| Deep Packet Inspection services | Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL | ||
| Content Filtering Service (CFS) | HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists | ||
| Comprehensive Anti-Spam Service | Yes | ||
| Application Visualization | Yes | ||
| Application Control | Yes | ||
| Capture Advanced Threat Protection | Yes | ||
| Networking | TZ570 SERIES | ||
| IP address assignment | Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay | ||
| NAT modes | 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode | ||
| Routing protocols4 | BGP, OSPF, RIPv1/v2, static routes, policy-based routing | ||
| QoS | Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM) | ||
| Authentication | LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC) | ||
| Local user database | 250 | ||
| VoIP | Full H.323v1-5, SIP | ||
| Standards | TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3 | ||
| Certifications | Granted: FIPS 140-2 Level 2 (with Suite B), IPv6/USGv6, ICSA Network Firewall, ICSA Firewall Enterprise, ISCA Network Antivirus / AntiMalware | ||
| High availability | Active/Standby with stateful synchronization | ||
| Hardware | TZ570 SERIES | ||
| Form factor | Desktop4 | ||
| Power supply | 60W external (TZ570/570W), 180W external (TZ570P only) | ||
| Maximum power consumption (W) | 13.4 (TZ570), 15.3 (TZ570W), 108.75 (TZ570P) | ||
| Input power | 100-240 VAC, 50-60 Hz | ||
| Total heat dissipation (BTU) | 44.7 (TZ570), | ||
| Dimensions | 1.38 inches (3.51 cm) ×5.91 inch (15.01 cm) × 8.85 inch (22.48 cm) | ||
| Weight | 2.14 lb (0.97 kg) (TZ570), 2.18 lb (0.99 kg) (TZ570W), 2.31 lb (1.05 kg) (TZ570P) | ||
| WEEE weight | 3.13 lb (1.42 kg) (TZ570), 3.24 lb (1.47 kg) (1.47 kg) (TZ570W), 3.46 lb (1.57 kg) (TZ570P) | ||
| Shipping weight | 4.25 lb (1.93 kg) (TZ570), 4.36 lb (1.98 kg) (TZ570W), 4.58 lb (2.08 kg) (TZ570P) | ||
| MTBF (in years) | 26.1 (TZ570), 23.3 (TZ570W), 31.7 (TZ570P) | ||
| Environment (Operating/Storage) | 32 °F (0 °C) -105 °F (-76.11 °C) / -40 °F (-40 °C) to 158 °F (70 °C) | ||
| Humidity | 5-95% non-condensing | ||
| Regulatory | TZ570 SERIES | ||
| Major regulatory compliance (wired models) | FCC Class B, FCC, ICES Class B, CE (EMC, LVD, RoHS), C-Tick, VCCI Class B, UL/cUL, TUV GS, CB, Mexico DGN notice by UL, WEEE, REACH, BSMI, KCC/ MSIP, ANATEL | ||
| Major regulatory compliance (wireless models) | FCC Class B, FCC P15C, FCC P15E, ICES Class B, ISED/ IC, CE (RED, RoHS), C-Tick, VCCI Class B, Japan Wireless, UL/cUL, TUV GS, CB, Mexico DGN notice by UL, WEEE, REACH, BSMI, NCC (TW) KCC/MSIP, SRRC, ANATEL | ||
| Major regulatory compliance (PoE models) | FCC Class A, ICES Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, UL/ cUL, TUV/ GS, CB, Mexico DGN notice by UL, WEEE, REACH, BSMI, KCC/ MSIP, ANATEL | ||
| Integrated Wireless5 | 570W | ||
| Standards | 802.11a/b/g/n/ac Wave 2, WEP, WPA, WPA2, 802.11i, TKIP, PSK,02.1x, EAP-PEAP, EAP-TTLS | ||
| Frequency bands | 802.11a: 5.180-5.825 GHz; 802.11b/g: 2.412-2.472 GHz; 802.11n: 2.412-2.472 GHz, 5.180-5.825 GHz; 802.11ac: 5.180-5.825 GHz | ||
| Operating channels | 802.11a: US and Canada 12, Europe 11, Japan 4, Singapore4, Taiwan 4; 802.11b/g: US and Canada 1-11, Europe 1-13, Japan (14-802.11b only); 802.11n (2.4 GHz): US and Canada 1-11, Europe 1-13, Japan 1-13; 802.11n (5 GHz): US and Canada 36-48/149-165, Europe 36-48, Japan 36-48, Spain 36-48/52-64; 802.11ac: US and Canada 36-48/149-165, Europe 36-48, Japan 36-48, Spain 36-48/52-64 | ||
| Transmit output power | Based on the regulatory domain specified by the system administrator | ||
| Transmit power control | Yes | ||
| Data rates supported | 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps per channel; 802.11b: 1, 2, 5.5, 11 Mbps per channel; 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps per channel; 802.11n: 7.2, 14.4, 21.7, 28.9, 43.3, 57.8, 65, 72.2, 15, 30, 45, 60, 90, 120, 135, 150 Mbps per channel; 802.11ac: 7.2, 14.4, 21.7, 28.9, 43.3, 57.8, 65, 72.2, 86.7, 96.3, 15, 30, 45, 60, 90, 120, 135, 150, 180, 200, 32.5, 65, 97.5, 130, 195, 260, 292.5, 325, 390, 433.3, 65, 130, 195, 260, 390, 520, 585, 650, 780, 866.7 Mbps per channel | ||
| Modulation technology spectrum | 802.11a: Orthogonal Frequency Division Multiplexing (OFDM); 802.11b: Direct Sequence Spread Spectrum (DSSS); 802.11g: Orthogonal Frequency Division Multiplexing (OFDM)/Direct Sequence Spread Spectrum (DSSS); 802.11n: Orthogonal Frequency Division Multiplexing (OFDM); 802.11ac: Orthogonal Frequency Division Multiplexing (OFDM) | ||
*Future use. 1 Testing Methodologies: Maximum performance based on RFC 2544 (for firewall). Actual performance may vary depending on network conditions and activated services. 2 Threat Prevention/GatewayAV/Anti-Spyware/IPS throughput measured using industry standard Spirent Web Avalanche HTTP performance test and Ixia test tools. Testing done with multiple flows through multiple port pairs. Threat Prevention throughput measured with Gateway AV, Anti-Spyware, IPS and Application Control enabled. 3 VPN throughput measured using UDP traffic at 1280 byte packet size adhering to RFC 2544. All specifications, features, and availability are subject to change. 4 BGP is available only on SonicWall TZ400, TZ500 and TZ470. 5 All TZ integrated wireless models can support either 2.4GHz or 5GHz band. For dual-band support, please consider using SonicWall’s wireless access point products. | |||
Additional information
| Weight | 6 lbs |
|---|---|
| Dimensions | 10 × 7 × 3 in |
