A24-3a
Original price was: $61.99.$55.78Current price is: $55.78.
Dahua A24-3A 24VAC 3A Power Adapter
- Input: AC 100V~240V 50/60Hz
- Output Voltage: DC 24V (constant voltage)
- Output Current & Wattage: Max 3A 72W
- Output DC connector:5.5mm x 2.5mm (inside”+”, outside”-”)
- AC input power cable length: 59in / 150cm
- DC output power cable length: 43.3in / 110cm
- Adapter body size: 7.01 inch (17.81 cm) (L) x 4.33 inch (11 cm) (W) x 3.15 inch (8 cm) (H)
- Working Temperature: 14 °F (-10 °C) to 104 °F (40 °C)
SKU: 816116023143
Categories: Accessories, Power Supply Adapter
Tags: 24 V DC power, 3A Power Adapter, A24-3A, Power Supply Adapter
Brand: Dahua Technology- Description
- Attachment
- Additional information
Description
Dahua Technology A24-3A 24 VAC, 3A Power Adapter
The A24-3a black 24 VAC, 3A Power Adapter from Dahua Technology provides power to devices requiring 24 VAC, 3A voltage. It features a two-prong plug.
Input: AC 100V – 240V, 50 / 60Hz ; Output: DC 24V, Max 3A, 72W ; It can supply with all amperage less than 3A. —such as 500mA, 800mA, 1A, 2.5A, 3A. If your device draws 2A, then 2A will be supplied. But if draws more than 3A, only 3A will be supplied and power supply will be damaged soon. NEVER OVERLOAD!
A24-3a is certified by FCC, CE, ROHS. We focus on producing high quality power adapters. No noise, low temperature operation, no spontaneous combustion, no explosion, no fire hazard, stable output. Automatic overload cut-off, over voltage cut-off, automatic thermal cut-off, short circuit protection.
A24-3a is perfect for 5050 3528 24V LED Strip Light, Wireless Router, ADSL Cats, HUB, Security Cameras, Audio/ Video Power Supply, 3D Printer, LED Driver, CCTV Security System, LCD Monitor, Webcam Router and other 24V devices. This product is an AC to DC adapter, NOT a charger!!! A24-3a can’t be used to charge electronic devices with batteries, such as laptops. Otherwise, it may damage your device.
A24-3A Electrical
- Input 120 VAC, 60 Hz
- Output 24 VAC (±5%), 3A
- Has spliced ends for terminal block connection
A24-3A Environmental
- Operating Temperature –10 °C to +40° F (14 °F to 104 °F)
- Storage Temperature –5 °C to +60° F (23 °F to 140 °F)
- Operating Humidity 30% to 85%, Relative
Physical Properties of A24-3A
- Weight 1645 g (3.63 lb)
- Dimensions (L x W x H) 120.0 mm x 80.0 mm x 65.0 mm (4.72 in. x 3.15 in. x 2.56 in.)
- Installation Mode Plane Installation
- Color Black
- Input Plug 2-pin North American Plug
- Cord Lengths Input: 1 m (3.28 ft)
- Output: AWG18 x 2C; 1.83 m (6.0 ft)
Certifications
- Safety CE, UL, SAA
Additional information
| Weight | 3.63 lbs |
|---|---|
| Dimensions | 7.01 × 4.33 × 3.15 in |
